零件号码 零件名称 件数 备注 零件号码 零件名称 件数 备注
Parts No. Name of Parts
QTY Parts No. QTY Remarks
LN1067-0A 轴承盖(
小
)--------
-
Bearing Cover(Small)-------------------------
-
1 ZMB02503
螺
丝--------------
-
Screw(M2.5-0.45×4)-----------
-
1
LN1069-0A
盖板(
小
)-----------
-
Bearing Plate(Small)---------------------------
-
3 ZMB03020
螺
丝--------------
-
Screw(M3-0.5×5)---------------
-
1
LN1076-0A
盖板垫(
小
)--------
-
Bearing Cover(Small)Gasket------------
2 ZMB03513
螺
丝--------------
-
Screw(M3.5-0.5×5.8)----------- 2
LN1077-0A
皮带盖(
下
)--------
-
Vertical Belt Cover(Lower)-------------
1 ZMB04065
螺
丝--------------
-
Screw(M4-0.7×10)-------------- 5
LN1078-0A
盖板(
大
)-----------
-
Bearing Plate(Large)---------------------------
-
1 ZMB14001
螺
丝--------------
-
Screw(M14-1×5)----------------
-
1
LN1079-0A
盖板垫(
大
)--------
-
Bearing Cover(Large)Gasket------------
1 ZMB14002
螺
丝--------------
-
Screw(M14-1×6.2)-------------- 1
LN1080-0A
皮带盖(
上
)--------
-
Vertical Belt Cover(Upper)--------------
1 ZMC04004
螺
丝--------------
-
Screw(M4-0.7×6)---------------
-
12
LN1081-0A
皮带盖(
中
)--------
-
Vertical Belt Cover(Medium)-----------
1 ZMH04001
螺
丝--------------
-
Screw(M4-0.7×4)---------------
-
4
LN4000-0A
筒形座-------------
-
Sewing Cylinder--------------------------- 1 ZMJ04024
螺
丝--------------
-
Screw(M4-0.7×10)-------------- 8
LN4051-0B
支轴----------------
-
Cylinder Front Cover Pin----------------
2 ZMJ08007
螺
丝--------------
-
Screw(M8-1.25×20)------------
-
4
LN4052-0A
圆筒盖-------------
-
Cylinder Top Cover----------------------- 1 ZMQ04010
螺
丝--------------
-
Screw(M4-0.7×16)-------------- 3
LN4053-1A
盖板组合----------
-
Cylinder Top Cover(Inner)--------------
1 ZMQ04012
螺
丝--------------
-
Screw(M4-0.7×12)-------------- 3
LN4053-2A
盖板组合----------
-
Cylinder Top Cover(Inner)--------------
1 ZMQ04013
螺
丝--------------
-
Screw(M4-0.7×5)---------------
-
4
LN4054-0A
下钩针罩----------
-
Cylinder Front Cover---------------------
1
LN4055-1A
左挡架-------------
-
Fabric Guide(Left)------------------------------
-
1
LN4056-1A
右挡架-------------
-
Fabric Guide(Right)----------------------------
-
1
LN4057-0A
线链切刀----------
-
Thead Chain Cutting Knife--------------
1
LN5221-0B
卡簧板-------------
-
Cover Latch Spring-----------------------
1
OPP00400
O
型
环--------------
-
O-ring---------------------------------------
2
SEC1050450
油塞----------------
-
Seal Plug-----------------------------------
2
SEC1500800
油塞----------------
-
Seal Plug-----------------------------------
1
SEC1750400
油塞----------------
-
Seal Plug-----------------------------------
2
SEC1800400
油塞----------------
-
Seal Plug-----------------------------------
2
SEN0950400
油塞----------------
-
Seal Plug-----------------------------------
5
SEN1050450
油塞----------------
-
Seal Plug-----------------------------------
3
SEN1250400
油塞----------------
-
Seal Plug-----------------------------------
1
SEN1550750
油塞----------------
-
Seal Plug-----------------------------------
1
SEN1800400
油塞----------------
-
Seal Plug-----------------------------------
3
YA080300
定位销-------------
-
Pin-------------------------------------------
2
Name of Parts
2.　CSN-1400　本体机构（二）　ARM BED AND ITS ACCESSORIES （二）
Remarks
5
GOLDEN WHEEL
