Linksys E3000 [30/80] Storage disk

High Performance Wireless-N Router

Linksys E3000 Chapter 3: Advanced Configuration

Storage > Disk

Your Linksys E3000 has a USB port on the back of the

Router. This allows you to connect an external USB drive

and access the contents over the network.

Reset

Internet

Ethernet4 3 2 1

Power

12VDC

USB

When a USB drive is connected to the USB port of the

Router, a shared folder titled public is automatically

created and shared on the USB drive. You can access the

contents via Windows Explorer or the Mac Finder. For

details on accessing the contents, refer to How to Install

and Access USB Storage - Overview, page 45.

The Storage options can be edited in the browser-based

utility when a USB drive is plugged in.

The Disk screen describes the disk (USB drive) currently

attached to the Router. Use this screen to create shared

folders, safely remove a disk, or format a disk (any data on

the disk will be deleted during formatting).

Shared folders are folders on the disk that are accessible

via the network. You can specify individual folders that

you want shared or share the entire partition. By default,

existing files and folders are not shared on a disk that is

plugged in for the first time. The only folder that is shared

by default is the public folder that is automatically created.

You can manually provide access to additional folders and

grant access to specific users or groups.

Storage > Disk

Disk Management

If a formatted disk is connected to the Router, then its name

is displayed. For each partition of the disk, the Partition,

File System, Capacity, and Free Space information are

displayed.

Safely Remove Disk Before physically disconnecting a

disk from the Router, click Safely Remove Disk first. This

prevents the possible loss of data, which may occur if you

remove the disk while it is transferring data.

Create Share To create a shared folder, click this option

for the appropriate partition, and the Shared Folder screen

appears.

Create Share > Shared Folder

Use this screen to create a shared folder.

Shared Folder

Display Name Create a name for the folder. This will

appear in the Shared Folder table on the Disk screen.

Partition The name of the partition is displayed.

Location The location of the current folder is displayed.

If you haven’t selected a folder or shared the partition, a

location will not be displayed.

New Folder Type in a new folder name if you want to

create a new subfolder in the current location. Then click

Create.

Share entire Partition Select this option if you want

to share the entire partition. If your disk doesn’t have

multiple partitions, selecting this option will share the

entire disk. If you do not want to share the entire partition,

then select the folder you do want to share.

Enter into Folder Select to go into the specified sub-

folder.
