Vacuum cleaner AS282K (Ref. 8200200)

Technical information

Explosion drawing and parts list

DP080415D00

(*) Parts not mounted in the current version

Pos. Code

ItemVrs. Serie

Pos. Code

ItemVrs. Serie

1 8245343 CABLE

2 8202318 CORD ARMOR

3 8202319 CORD CLAMP

4 8279005 SCREW D.5X20 BZ

5 8202337 HOOK

6 8279006 SCREW D.5X35 BZ

7 8202338 HANDLE

8 8279010 SCREW D.5X50 BZ

9 8279009 SCREW D.5X15 BZ

10 8268245 TERMINAL

11 8268244 CAPACITOR

12 8202339 UPPER COVER

13 8219243 LABEL

14 8215046 SWITCH

15 8299162 FILTER

16 8299177 RUBBER

17 8202340 MOTOR COVER CAP

18 8202341 MOTOR COVER

19 8202342 MOTOR PRESSER

20 8299163 WASHER

21 8204209 MOTOR COVER

22 8204208 L-JOINT

23 8269043 MOTOR ASS’Y 230 V.

24 8202343 COVER

25 8299213 ELECTRONIC CIRCUIT+CLAMPS

26 4368022 PILLAR TERMINAL

27 8299178 FOAM

28 8299182 SELF-ADHESIVE FOAM

29 8202344 MOTOR BASE COVER

30 8202345 HEAD BASE

31 4468072 SOCKET

32 8273032 SCREW M.4X16

33 2385005 HEX. NUT M.4

34 8202332 TANK LOCKER

35 8289052 RIVET

36 8202691 D0 3200 TANK

* 36 - 8202348 TANK

* 36 - 8245923 TANK ASS’Y (SPARE)

37 8279004 SCREW D.5X30 BZ

38 8299171 JOINT

39 8299170 JOINT

40 8202333 FAN DEFLECTOR

41 8202334 ASPIRATION NOZZLE D.38

42 8245344 PUSH BUTTON

43 8226121 SPRING

44 8219119 LABEL

* 45 8202349 PROTECTOR

46 8202351 WASHER

47 8202350 HANDLE

48 8202676 D0 3200 BASE

* 48 - 8202352 BASE

49 8299590 D0 3200 WHEEL

* 49 - 8299181 WHEEL ASS’Y

50 8299173 Y CONNECTOR D.32

51 8299077 DUST COLLECTION PIPE 3 M

52 8202330 LOCKER

53 8299169 PAPER FILTER

54 8299180 FILTER

55 8202347 TURNBUCKLE

56 8202346 FILTER HOLDER RING

57 8202328 BUOY

58 8299179 RACK

59 8202327 NO-SCUM BODY

60 8279008 INOX SCREW D.5X25 BZ

61 8202326 STOPPER

62 8202422 B0 BRACKET

63 8299214 B0 ELECTRONIC CIRCUIT

64 8217033 CARBON BRUSHES SET

65 5080007 D0 3200 WASHER D.10.5 DIN125

66 8280073 D0 3200 WASHER D.10.5X30X2.5

67 8285056 D0 3200 NUT M.10

S/P 8294226 CARTON BOX
