No-load speed...................................................14,000 – 30,000/min
Ø max bit..........................................................................25 mm
Ø standard chuck collet.......................................................6 & 8 mm
Weight....................................................................................2.2 Kg
Weighted equivalent continuous
acoustic pressure level A.........................................................83 dBA
Acoustic power level A.............................................................94 dBA
Uncertainty......................................................................K = 3 dbA
Wear ear protection!
Vibration total values.................................................a
h
: 3.1 m/s
2
Uncertainty....................................................................K: 1.5 m/s
2
3. STANDARD EQUIPMENT
Inside the carrying case the following items will be
found:
• FR292R Router with 8 mm collet (*)
• Straight cutter for trimming and slotting D.18 LC. 20
• Key: 11 mm for motor shaft.
• Key: 19 mm for chuck collet attachment.
• Copying device
• Bit bearing brake
• Lateral square with centring shaft
• 3-mm Allen wrench
• Operating instructions and other documents
(*) (Machines at 120 V are equipped with 6.35 mm (1/4")
collet.)
4. GENERAL DESCRIPTION OF THE ROUTER
The FR292R router can be used for trimming laminates,
shaping small mouldings, rabbeting, making straight cut-
outs, chamfering, etc. Its head may be tilted from 0 to 91.5°
to cut bevelled edges and chamfer using cylindrical cutters
plus many more applications.
It micrometric copying wheel also allows interior curves
with radii over 52 mm to be cut.
It can also cut copies from templates using the copiers or the
template guides shown in section 11 and it can cut or shape
circles using the lateral square and centring shaft.
5. ASSEMBLY OF THE ROUTER AND ITS ACCESSORIES
5.1 ASSEMBLING AND CHANGING THE CUTTER
Make sure you place the chuck collet in
the correct position, otherwise vibrations
may occur or the part itself my come loose
(Fig. 23).
Disconnect the machine from the power
supply before assembly.
To change or assemble a cutter in the machine (Fig. 1), block
the motor shaft using the key U, unscrew the nut using
the service key Z, take out the used cutter and attach the
new one placing it into the bottom of its housing and then
tighten using the service keys.
Check that the stem diameter of the chuck collet
matches that of the cutter stem to be used.
5.2 ASSEMBLING THE FEELER AND BRAKE
Disconnect the machine from the power
supply before assembly.
Place copying device set M (Fig. 2), through holes O (Fig.
3) on the head and fix it at the required height using
screws H (Fig. 2).
5.3 ASSEMBLING THE LATERAL SQUARE
Disconnect the machine from the power
supply before assembly.
Place lateral square W (Fig. 5), through holes C (Fig. 4) on
the head and fix it at the required height using screws H.
5.4 ASSEMBLING THE CENTERING DEVICE
Attach the central shaft in the position indicated in Fig. 6,
together with the spacer and the stop washer, and fix them
with the nut supplied.
5.5 ASSEMBLING THE BRAKE FOR BIT WITH BEA-
RINGS
The machine comes with the brake accessory for the bit
with bearings, which prevents the bearing's external support
track with the wood from turning together with the bit, thus
preventing damage to the panel when trimming the wood.
To attach the brake, proceed in the following manner:
Loosen stud M1 (Fig. 20) and remove the feeler from its
support, unscrewing it completely. Next, fit the brake
assembly in the support, adjusting it so that rubber spline
R1 is supported on the external bearing track R2 of the bit,
without exerting excessive pressure, as this could decentre
it. (Fig. 21 and 22). Next attach stud M1 again.
6. ADJUSTMENTS
6.1 ADJUSTING HEAD TILT
Disconnect the machine from the power
supply before adjustment.
With the FR292R router, head tilt may be set for the cutter
