Virutex PEB200TRC+ [2/7] Parts list 2

PEB200 edgebander (Ref. 5000900)

Technical information

Explosion drawing and parts list

DP 130515D0

(*) Parts not mounted in the current version

Pos. Code

ItemVrs. Serie

Pos. Code

ItemVrs. Serie

131 8578030 SCREW M4X8 TORX

132 8580072 WASHER

133 8585053 SPACER

134 8802692 HANDLE

135 9075003 HEX. SOCKET HD. CAP SCREW M.8X35

136 9280063 WASHER D. 5.1X13X1.5

137 2571042 SCREW M.5X12

138 5046544 SWITCH ASS’Y

* 139 5087160 TIGHTENING PINION

140 4385013 C0 12116 NUT M.5

141 5022691 C0 12116 ROLLER TIGHTENER

142 6622172 C0 12116 SPACER

143 5023969 C0 12116 SUPPORT

144 2280004 C0 12116 WASHER D.5.2X11.1X0.7

* 145 5578031 C0 12116 SCREW M5X10 TORX

146 1380024 C0 12116 WASHER 8.2X19X0.1

147 5004288 D0 12131 ROLLER

S/P 5077030 RING

S/P - 5046426 TEMPLATE BASE ASS’Y
