Quick start guide

Installation Notes

WARNING

• Please note the position of pipes, tanks and electrical wirings before

installing the unit into the vehicle; failure in avoiding these may

cause a re or malfunction.

CAUTION

• Use only the supplied parts.

If unspecied parts are used, they may cause damage.

• Any holes made in the body of the vehicle should be sealed with

a silicon adhesive. If exhaust fumes or water penetrates into the

vehicle, this may cause an accident.

• Fasten the bolts securely when installing the unit. If the bolts are

loose an accident or malfunction could occur.

Connection Notes

WARNING

• Loom all cables according to the instruction manual, so as not to

hinder operation.

• Wire the connecting cords/cables away from high temperature areas.

If the coatings of the cables melt, it could cause an accident/re by a

short circuit. Take care when wiring in the engine compartment.

• When wiring the connecting cables in a vehicle with an airbag

system, never feed the cables through a place where it may aect

the operation of the airbag. An airbag not operating correctly in an

emergency may cause increased injury.

CAUTION

• Verify wires with a digital multi-meter prior to making any

connections. Many new vehicles use multiplexed and/or low voltage

circuits that can be damaged if a test light or logic probe is used.

• Connect cables appropriately. If a wrong connection is made, this

may cause a re or accident.

• When passing cables through the body of the vehicle, use non-

conductive grommets. If the coatings of the cables are worn out by

rubbing, this may cause an accident, re or a short circuit.

• After wiring cables, x them with insulation tape.

• Be sure to switch o the vehicle when connecting or disconnecting

cords to/from the unit, otherwise an electric shock, injury or accident

may occur.
