PR2000, PR2500 Operating the awning

7 Operating the awning

Observe the safety instructions in chapter “Safety instructions” on page 9.

7.1 Note on the vehicle location

7.2 Extending the awning

➤ Click the hand crank into the holder in the awning (fig. 1, page 3).

➤ Turn the hand crank until the awning is extended by about 1.5 m (fig. 2,

page 3).

➤ Slide the right strut into the front cover completely together so that you

can move them freely (fig. 3, page 4).

➤ Turn the right strut to the side (fig. 3, page 4).

➤ Fold the right strut down and set it on the ground (fig. 4, page 5).

➤ Adjust the strut to the required height (fig. 5, page 5).

➤ Fold the lever of the strut up to secure the struts (fig. 6, page 6).

➤ Extend the other strut in the same way.

➤ Turn the hand crank until the awning is extended to the required position.

After a few revolutions, position the struts vertically under the front panel

again so that the awning stays secured at all times.

➤ Turn the hand crank approx. a quarter of the way back to tighten the

fabric.

NOTICE!

 Park the vehicle so that no debris (branches, leaves or similar)

gets on to the fabric.

 Keep the awning free of dirt to prevent abrasions, stains and

mildew.

WARNING! Beware of injury

Keep a sufficient distance from objects or other vehicles. Once it

is retracted, it should be at least 40 cm away from other objects

and vehicles.
