6D SERVOLINER

MEASUREMENT FOUNDATION

Operation

1. Take out the battery lid. According the sign “ + ,-”, insert four“ + ,-”, insert fourinsert four

alkaline batteries or rechargeable batteries to the battery socket, then

cover the battery lid.

2. Setting up the instrument on the floor or the tripod. When using tripod,

support the centering nut of the instrument with one hand and screw

the centering screw into the centering nut female thread. Tighten the

upper part of the instrument to roughly adjust vertical to find objects

correctly.

5. When the instrument inclines over alarm range, because of certain reason during the operation, the laser and the LEDWhen the instrument inclines over alarm range, because of certain reason during the operation, the laser and the LED

will blink and buzzer sounds at the same time, the laser line gleams. This time, please adjust the three leveling screws to make

the buzzer sound stop.

27
