6D SERVOLINER
MEASUREMENT FOUNDATION
Slant/slope fine adjustment mode
1. After power on, pressing “power button” for a little bit time enter (or quit) “slant / slope fine adjustment mode”/ slope fine adjustment mode”slope fine adjustment mode”
2. Entering “slant / slope fine adjustment mode” all H lines are ON automatically, (photo-1)/ slope fine adjustment mode” all H lines are ON automatically, (photo-1)slope fine adjustment mode” all H lines are ON automatically, (photo-1)
3. Setting “slant fine adjustment [X axis]” for start point.
4-1. During the time of “slant fine adjustment [X axis]”, pressing D can be switched to “slope finepressing D can be switched to “slope fine
adjustment [Y axis]” (V/D LED light) (photo-2)
pressing V can make the elevation angle of H line go down,
pressing D can make the elevation angle of H line go up. 4-2.4-2.
4-2. During the time of “slope fine adjustment [Y axis]”, pressing H can be switched to “slant finepressing H can be switched to “slant fine
adjustment [X axis]” (H/V LED light)
pressing H can make the left side of H line go down,
pressing V can make the right side of H line go down.
5. Bi-Bi sound mentions the already reaches the limit.
Photo-1 Photo-2
28
