Navitel MSR200 [12/13] Device functions

NAVITEL MSR200 | 11

Device functions

Video Connect the device to an external power supply and it will start recording automatically (indicated by the

ashing blue light). Press the OK button to stop recording (the blue light will become steady). Press OK again

to record another video. Each video will be saved automatically.

Photo In Video Recording mode (STBY), press the Power button to enter Capture mode, press the OK button to take

a photo (it will be saved automatically).

Playback In Video Recording mode (STBY), press the Power button twice to enter Playback mode; press the Up and

Down buttons to select a le; press the OK button to play a le. During playback, press OK to pause/unpause;

press the Up and Down keys to fast forward/rewind.

Record audio Record video with or without sound.

Lock le In Video Recording mode (REC), press Power to protect the current recording. A key symbol will appear at the

bottom of the screen. In Playback mode, select a le, press Menu and select Protect, then Lock Current or Lock

All. Protected les cannot be deleted or overwritten. Select Unlock Current / Unlock All to remove protection.

Loop recording This setting allows saving the recording in separate les every few minutes. For example, if set to

5 minutes, 1 hour of footage will be saved as 12 ve-minute fragments. If the memory card is full, all

unprotected les will be overwritten in the order they were created.

G-sensor If the vehicle is hit by something, the DVR will automatically lock the current video.

Parking monitor In shutdown state, if vibration is detected, the device will turn on automatically and start recording. The le

will be protected (locked). If nothing happens for over 10 seconds, the device will shut down.

Motion detection When an object is moving the device will automatically start recording. If the object does not move for more

than 5/10/30/60 seconds, recording stops.

Stamp This function adds date stamp to the record.

Battery Red indicator lights up when the device is plugged into an external power supply; as the battery is charging,

the red light will gradually dim; the red light going out means the battery is full.

Screen Saver The device can automatically shut o the screen to reduce power consumption; time interval can be set in

the Screen Saver menu.
