Quick Start Guide

Replacing the switches

NOTE:Refertowww.asus.comforthelistofcompatibleswitches.

Ifyouwanttoreplacetheswitches,followthestepsbelow:

1. Removethefour(4)screwsandsetitaside.

2. Remove the top cover.

3. Replacetheswitches.

IMPORTANT!

• Ensuretoinstalltheswitchintotheswitchsocketwithitsbuttonfacingthefrontofthemouse.

• Ensurethattheswitchesareseatedproperlyintheswitchsockets.

4. Placethetopcoverandsecureitwiththefour(4)screws.

Switch

socket

Switch

socket

Mouseswitches

To update your wireless receiver/charging dock rmware:

1. Launch ROG Armoury.

2. ConnectthemicroUSBcabletoyourwirelessreceiver/chargingdock.

3. Click Nextonthepopupwindowtostartthermwareupdate.

NOTE:Thepopupwindowwillonlyappearifthereisanewrmwareupdateavailable.

IMPORTANT!Whenyouencounteraproblemwhileupdatingthermware,unplugthemicroUSB

cable,thenpressandholddownthePairbuttononthewirelessreceiver/chargingdockandreplug

themicroUSBcabletorestarttheupdate.
