53 & 54 Series II
Users Manual
20
General
Weight 280 g (10 oz)
Dimensions
(without
holster)
2.8 cm × 7.8 cm × 16.2 cm
(1.1 in × 3 in × 6.4 in)
Battery 3 AA batteries
Certification P,
s
Safety CSA C22.2 No. 1010.1 1992
EN 61010 Amendments 1, 2
CAT I OVERVOLTAGE (Installation)
CATEGORY I, Pollution Degree 2 per
IEC1010-1*
* Refers to the level of Impulse Withstand Voltage protection
provided. Equipment of OVERVOLTAGE CATEGORY I is
equipment for connection to circuits in which measures are
taken to limit the transient over voltages to an appropriate low
level. Example include protect electronic circuits.
80 PK-1 Thermocouple (supplied with
thermometer)
Type Type K, Chromel Alumel, bead style
Temperature
Range
−40
o
C to +260
o
C
(−40
o
F to +500
o
F)
Accuracy ± 1.1
o
C (± 2.0
o
F)
Electrical
Measurement
Range
J-type: −210
o
C to +1200
o
C
(−346
o
F to + 2192
o
F)
K-type: −200
o
C to +1372
o
C
(−328
o
F to +2501
o
F)
T-type: −250
o
C to +400
o
C
(−418
o
F to +752
o
F)
E-type: −150
o
C to +1000
o
C
(−238
o
F to +1832
o
F)
N-type: −200
o
C to +1300
o
C
(−328
o
F to +2372
o
F)
R- and S-type: 0
o
C to +1767
o
C
(+32
o
F to +3212
o
F)
Display
Resolution
0.1
o
C /
o
F / K < 1000
o
1.0
o
C /
o
F / K ≥ 1000
o
