7. CONNECTION

Connect a DVD or VHS etc. video devices to this receiver to appreciate a high quality picture.

1). VCD, DVD or Other Video Devices “S-Video” Connection

Connect the “S-Video” input terminal and “Audio Input” terminals of this receiver with “S-video” output terminal and “Audio Output” ter-

minals of VCD, DVD, VHS or other video devices; press the “MODE” button on the remote control or on the receiver button board to select

“S-Video” to get the program input.

2). VCD, DVD or Other Video Devices “AV” Connection

Connect the “AV” input video and audio terminals of this receiver with “AV” output video and audio terminals of VCD, DVD, VHS or other

video devices; press the “MODE” button on the remote control or on the receiver button board to select “AV” to get the program input.

3). DVD Component Connection

Connect the “Y, Cb (Pb), Cr (Pr)” DVD component input terminals and “Audio Input” terminals of this receiver with “Y, Cb (Pb), Cr (Pr)”

DVD component output terminals and “Audio Output” terminals of a DVD player; press the “MODE” button on the remote control or on

the receiver button board to select DVD Component “Y, Cb (Pb), Cr (Pr)” to choose the program input.

4). Analog RGB (PC) Connection

Connect the “VGA” analog RGB input terminal of this receiver with “VGA” analog RGB output terminal of a person computer; press the

“MODE” button on the receiver button board or on the remote control to select “PC” to appreciate the program input.

5). Digital RGB (DVI) Connection

Connect the “DVI” digital RGB input terminal of this receiver with “DVI” digital RGB output terminal of a person computer; press the

“MODE” button on the receiver button board or on the remote control to select “DVI” to appreciate the program input.

6). SCART Connection

Connect the “SCART AV (RGB)” input terminal of this receiver with signal generator, press the “MODE” button on the receiver button

board or on the remote control to select “SCART” to appreciate the program input.

The “SCART” mode will be superior to the others, when the “SCART” signal is inputed.

The displaying resolution of the receiver is 1366x768 (26” 32” 40”) which supporting PC 1366x768(26” 32” 40”) (32bite true color)

format and any lower format. The receiver can detect the format of input signals automatically and adjust to achieve the best result.

Employ at least a 640x480 (refresh frequency 60Hz) or higher format before connecting the PC signals to ensure the receiver works

in sync with the computer.

When there is no signal connected to DVI, RGB, S-Video, Video, Y, Cb (Pb), Cr (Pr), SCART mode, the LCD TV will switch to sleep-

ing mode. As a signal is connected or you press the “MODE” button on the TV or remote control, the screen will resume operation.
