Analog RGB Operation (PC)
“PICTURE” Operation
When receiving RGB (PC) signal, press the “MENU” button firstly on the receiver button board or on the remote control to get into the
Picture menu; press “CH+” or “CH%” to select “PICTURE” item, and then press the “VOL+” or “VOL%” to adjust.
Connect audio connecting cable to “AUDIO 2” terminals of this receiver.
When receiving RGB (PC) signal, press the “MENU” button secondly on the receiver button board or on the remote control to get into
the “Picture” menu; press “CH+” or “CH%” to select “PICTURE” item, and then press the “VOL+” or “VOL%” to adjust.
“SOUND” Operation
When receiving RGB (PC) signal, press the “MENU” thirdly on the receiver button board or on the remote control to get into the Sound
menu; press “CH+” or “CH%” to select “SOUND” item, and then press the “VOL+” or “VOL%” to adjust.
“Setup” Operation
When receiving RGB (PC) signal, press the “MENU” fourthly on the receiver button board or on the remote control to get into the Setup
menu; press “CH+” or “CH%” to select “Setup” item, and then press the “VOL+” or “VOL%” to adjust.
26
OPERATION MANUAL
Sound
Bass 50 Press right/left to adjust Bass
Treble 50 Press right/left to adjust Treble
Balance +0 Press right/left to adjust Balance
Setup
Language English Press right/left to select Language
Source PC Press right/left to select Source
Osd Tone Off Press right/left to select Osd Tone
Size
Fill Screen
Press right/left to select Size
Brightness 50 Press right/left to adjust the brightness
Contrast 50 Press right/left to adjust the contrast
Phase 0 Press right/left to adjust the phase
Frequency 2200 Press right/left to adjust the Frequency
Horizontal 50 Press right/left to adjust the Horizontal position
Vertical 50 Press right/left to adjust the Vertical position
Reset Press right/left to enter the Reset
