2
3
General information
Item No. Fins Power, W
1005 5 1000
1006 6 1000
1507 7 1500
2009 9 2000
2511 11 2500
2512 12 2500
Important safeguards
Before use
Use of the item
Temperature control
Cleaning and technical service
Do not leave product unattended!
The importer retains his right to make changes in appearance and completeness
of the item without preliminary notification to the customer.
The item is for household use only.
Technical characteristics:
Voltage: 220V/50HZ
Service life is 2 years
Electric Oil Filled Radiator
Oil heaters should be used for heating residential and commercial premises.
The heaters are equipped with thermostat for automatic temperature control and also with
system of power control.
The items have got casters.
The following models are equipped with fan: IR-03t, IR-07t. The power of these models is
400W higher.
Power could be identified in accordance with below table:
Plug the heater in only the grounded socket.
Plug out heater when operate or move it and also when you wash floor near the item.
Do not use oil heater in rooms with high humidity.
Do not cover oil heater when it is operating
Do not place cord on the hot surface.
Use heater only in vertical position.
Do not place heater under wet clothes.
Do not switch on heater with damaged cord.
Do not use item in the rooms which are less than 4 m3
Read carefully instruction manual before first use.
The heater becomes hot when it is working. Avoid contact with hot surface to prevent burn.
Avoid ingress of water on the body.
Do not touch heater with wet hands. It can cause electric shock.
Avoid placing foreign objects in air vents of fan.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or metal capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
Take oil heater and casters out of the box.
Make sure that item was not damaged during transportation.
Turn the heater upside down and place on soft surface to avoid damage of the coating.
Mount casters on the baseboard in accordance with scheme.
The appliance should be connected to the same voltage as pointed on the rating label and
package.
Set power switch in off position.
Then set the thermostat handle in far left position counter clockwise.
Plug in the oil heater. Turn the thermostat handle clockwise until it stops.
Switch on the heater with help of power switches.
Attention! Gurgling sounds that appear when oil heater is operating are not the indicators of
defects of the product.
Attention! If item is equipped with fan, use it. It will fast heating process.
To switch on fan press the required button on the front panel.
Attention: smell of new item is possible when heater is used for the first time. Switch on the
item at maximum power for 2 hours and ventilate the room.
When the ambient temperature will reach desired rate, it is necessary to turn thermostat
handle counter clockwise until the indicator light switches off.
The position of thermostat handle will be set in accordance ambient temperature. The
temperature will be automatically controlled.
To switch off the oil heater set the power switches in off position. The thermostat handle
should be set in far left position. Plug the item out.
Attention! Never leave the oil heater unattended!
Oil heater does not need special care. It is enough to wipe it with soft cloth.
Before cleaning the item wait when it cools down and plug it out.
Do not use abrasives and solvents.
You can use vacuum cleaner for removing dust between fans.
The oil heater can be repaired only in service center.
Use extensions and adapters only for current not less than 16A.
Size without wheel
Fins
188*150*580mm
480*150*580mm
520*150*580mm
5
6
7
9
11
12
480*240*625mm
Size with wheel
188*240*625mm
520*240*625mm
224x150x580mm
260x150x580mm
332x150x580mm
224*245*620mm
260*245*620mm
332*245*620mm
Electric Oil Filled Radiator
