Epson GT-8500 [29/268] Halftoning

Halftoning

Halftoning adjusts the shade and color of each pixel according to the

shade and color of the surrounding pixels. Setting halftoning to large

results in a sharper contrast between dots. Setting halftoning to small

results in reduced contrast.

Overview 1-15
