IKA RT 15 0003692600 [11/64] Commissioning
![IKA RT 15 0003692600 [11/64] Commissioning](/views2/1544994/page11/bgb.png)
11
Unpacking
• Unpacking
- Please unpack the device carefully
- In the case of any damage a detailed report
must be sent immediately (post, rail or forwarder)
• Delivery scope
RO RT
- Magnetic stirrer - Heating magnetic-
RO 5/10 or 15 stirrer RT 5/10 or 15
- power supply unit - mains cable
- operating instruction - operating instruction
Correct use
• Use
- For mixing and / or heating liquids
• Range of use
Indoor environments similar to that a laboratory of research,
teaching, trade or industry area.
The safety of the user cannot be guaranteed:
- if the device is operated with accessories that are not supplied
or recommended by the manufacturer,
- if the device is operated improperly or contrary to the
manufacture’s specifications,
- if the device or the printed circuit board are modified by third
parties.
After the device is switched on a display self-test is performed.
The display cycles through the following information:
• All segments light up
• The software version and the selected mode are displayed
• The selected “Eco Mode” is displayed
(E when ECO mode is active)
• If the drive has not been started the display reads „OFF“. If
the drive has been started the selected speed is displayed.
Commissioning
RO/RT
Observe the ambient conditions (temperature, humidity, etc.)
listed under Technical Data.
The device is switched on and off via the switch (A) located on
the right-hand side of the device. On the front panel a small
arrow labelled Power above the display (B) indicates the location
of the switch.
Safe temperature limit
RT
The max. attainable heating plate temperature is restricted to 130
°C by a permanently set safety temperature limit. Once this limit
has been attained, the device switches off the heating.
The safe temperature limit must all-
ways be set at least 25 °C lower than
the fire point of the media to be
processed!
Setting the safe temperature limit
RT
The safety temperature is set as follows:
Switch the device on using the On/Off switch
on the right side of the device.
As soon as the display shows SAFE, press and
hold down the Temp membrane key and use
the +/- membrane keys (H or I) to set the
desired safety temperature.
The set safety temperature is displayed.
Once the Temp membrane key is released, the safety temperature
is saved.
RO/RT
The stirring function is started and stopped by pressing the „Start/
Stop“ button (C).
Pressing the +/- buttons (E or D) increases or reduces the speed.
Stirring function
WARNING
