IKA color squid white 0003671000 [19/35] Magnetic stirrers magnetic stirrers
![IKA color squid white 0003671000 [19/35] Magnetic stirrers magnetic stirrers](/views2/1544939/page19/bg13.png)
Max. stirring quantity (H₂O) 0,8 l
Motor rating input / output 5 / 3 W
Speed range 15 – 1500 rpm
Speed display –
Max. stirring bar length 25 mm
Speed adjustment stepless
Set-up plate material polyester
Set-up plate dimensions Ø 100 mm
Dimensions (W × D × H) 117 × 180 × 12 mm
Weight 0,3 kg
Permissible ambient temperature 5 – 40 °C
Permissible relative moisture 80 %
Protection class acc. to DIN EN 60529 IP 65
Voltage 100 – 240 V
Frequency 50 / 60 Hz
€ 256,00
TECHNICAL DATA
/// lab disc, Ident. No. 003907500 white
0003765000 pattern
0003916100 stream
Midi MR 1 digital
Ident. No. 0025002968
Maxi MR 1 digital
Ident. No. 0025002978
KMO 3 basic
Ident. No. 0020004631
Max. stirring quantity (H₂O) 50 l 150 l 5 l
Motor rating input / output 70 / 19 W 80 / 35 W 13 / 9 W
Speed range 0 – 1000 rpm 0 – 600 rpm 0 / 10 – 1,500 rpm
Speed display LCD LCD LED
Max. stirring bar length 80 mm 155 mm 80 mm
Speed adjustment stepless stepless 10 rpm steps
Set-up plate material stainless steel 1.4301 stainless steel 1.4301 glass
Set-up plate dimensions 350 × 350 mm 500 × 500 mm 140 × 120 mm
Dimensions (W × D × H) 360 × 430 × 110 mm 505 × 585 × 110 mm 153 × 227× 62,5 mm
Weight 10,7 kg 16 kg 1,2 kg
Permissible ambient temperature 5 – 40 °C 5 – 40 °C 5 – 40 °C
Permissible relative moisture 80 % 80 % 80 %
Protection class acc. to DIN EN 60529 IP 21 IP 21 IP 42
Voltage 220 – 240 V 220 – 240 V 220 – 240 V
Frequency 50 / 60 Hz 50 / 60 Hz 50 / 60 Hz
USB / RS 232 interface yes yes only USB
€ 2.805,00 € 3.098,00 € 749,00
TECHNICAL DATA
/// Comparison
36 37
Magnetic Stirrers Magnetic Stirrers
