![IKA color squid white 0003671000 [24/35] Accessories](/views2/1544939/page24/bg18.png)
Accessories
/// Stir bars
Technical data
/// Multi-position stirrers with heating function
STIR BARS
/// Comparison
Description
Dimensions
(L × Ø) Price
KAFLON
®
round
IKAFLON
®
10 Set (5 Pcs)
Ident-No. w
round,
PTFE-coated 10 × 6 mm € 7,00
IKAFLON
®
15 Set (5 Pcs)
Ident-No. 0004488700
round,
PTFE-coated
15 × 6 mm € 8,00
IKAFLON
®
20 Set (5 Pcs)
Ident-No. 0004488800
round,
PTFE-coated
20 × 8 mm € 9,00
IKAFLON
®
25 Set (5 Pcs)
Ident-No. 0004488900
round,
PTFE-coated
25 × 8 mm € 11,00
IKAFLON
®
30 Set (5 Pcs)
Ident-No. 0004489000
round,
PTFE-coated
30 × 8 mm € 11,00
IKAFLON
®
40 Set (5 Pcs)
Ident-No. 0004489100
round,
PTFE-coated
40 × 8 mm € 12,00
IKAFLON
®
50 Set (5 Pcs)
Ident-No. 0004489200
round,
PTFE-coated
50 × 8 mm € 13,00
IKAFLON
®
80 Set (5 Pcs)
Ident-No. 0004489300
round,
PTFE-coated
80 × 10 mm € 31,00
IKAFLON
®
110
Ident-No. 0000793300
round,
PTFE-coated*
108 × 27 mm € 268,00
IKAFLON
®
155
Ident-No. 0001129000
round,
PTFE-coated*
153 × 27 mm € 358,00
* Used for large magnetic stirrers like Maxi MR 1 digital.
* The admissible temperature range for PTFE-coated stirring bars is - 200 – 280° C.
RT 5
Ident. No. 0003690600
RT 10
Ident. No. 0003691100
RT 15
Ident. No. 0003692600
Number of stirring positions 5 10 15
Max. stirring quantity per
stirring position (H₂O)
0,4 l 0,4 l 0,4 l
Distance between stirring places 90 mm 90 mm 90 mm
Deviation for individual stirring positions 0 % 0 % 0 %
Speed range 0 – 1.000 rpm 0 – 1.000 rpm 0 – 1.000 rpm
Speed display LED line LED line LED line
Speed adjustment 10 rpm steps 10 rpm steps 10 rpm steps
Max. stirring bar length 30 mm 30 mm 30 mm
Heat output 175 W 375 W 580 W
Heating rate (1 l H
2
O in H15) 3 K / min 3 K / min 3 K / min
Temperature range heatig plate RT – 120 °C RT – 120 °C RT – 120 °C
Max. temperature medium
(dep. on vessel)
70 °C 70 °C 70 °C
Temperature display LED LED LED
Heat control accuracy ± 1 K ± 1 K ± 1 K
Set-up plate material aluminium alloy aluminium alloy aluminium alloy
Set-up plate dimensions 110 × 495 mm 180 × 495 mm 270 × 495 mm
Dimensions (W × D × H) 120 × 610 × 60 mm 190 × 610 × 60 mm 280 × 610 × 60 mm
Weight 4 kg 7,5 kg 10,5 kg
Permissible ambient temperature 5 – 40 °C 5 – 40 °C 5 – 40 °C
Permissible relative moisture 80 % 80 % 80 %
Protection class acc. to DIN EN 60529 IP 40 IP 40 IP 40
Voltage 220 – 240 V 220 – 240 V 220 – 240 V
Frequency 50 / 60 Hz 50 / 60 Hz 50 / 60 Hz
€ 2.125,00 € 2.844,00 € 3.558,00
TECHNICAL DATA
/// Comparison
46 47
Magnetic Stirrers Magnetic Stirrers
