5D CROSSPOINT

MEASUREMENT FOUNDATION

Operation

Set the instrument on the working surface or tripod/pillar (ADA Silver) or on wall/oor mount (in the kit).

- unlock compensator with locking knob (3). Move it to the position “On”.

Note: If the locking knob is in the position “OFF”, miss this step.

There is no indication on the keypad.

Press the Power Key to turn on laser beams: 1/2/3/4- it depends which mode you need:

- one press- horizontal plane

- two presses- vertical plane

- three presses- both horizontal and vertical planes

- four presses- dots

-ve presses- horizontal, vertical planes with dots

To turn on the mode of work “with receiver”, press the knob (2). In this mode you can work at large distances (to 30m) and in bright

illumination.
