Ebara DWO 200 M [4/4] Mechanical sea

Your Life, our Quality. Worldwide. Commercial

The contents of this publication must not be regarded as binding. EBARA Pumps Europe S.p.A. reserves the right to effect any modification it deems necessary, without prior notice.

M

ECHANICAL SEAL

standard M

ATERIALS TABLE

Ref. Name Materials

A

Rotating part Ceramic

B Fixed part Carbon

C O-Ring NBR

ELECTRIC DATA TABLE

230V 230/400V [HP] [kW] Single phase Three phase µF V

c

η %

Single phase Three phase Single phase Three phase

50% 75% 100% [kW] [kW] 230V 230V 400V

DWO 150 M DWO 150 1,5 1,1 - IE2 35 450 79,7 82,5 83,0 1,36 1,80 6,8 5,6 3,2

DWO 200 M DWO 200 2 1,5 - IE2 40 450 78,6 83,0 84,2 2,05 1,78 9,0 6,3 3,7

Ref. Name Materials

H version

Carbon

Tungsten Carbide

Tungsten Carbide

E O-Ring

FPM

FPM

FPM

FPM

F Spring

AISI 316L

Structure/frame

230V 230/400V [HP] [kW]

DWO 150 M DWO 150 1,5 1,1

<70

DWO 200 M DWO 200 2 1,5

- DWO 300 3 2,2

- DWO 400 43

* Mean value of several measures at 1m distance around the pump.

Tollerance ± 2.5 dB.
