5 | MultiDrive basic and control
TECHNICAL DATA MultiDrive basic MultiDrive control
Operating principle Cutting / impact Cutting / impact
Feed hardness max.
5 Mohs
(9 Mohs with hard metal knife)
5 Mohs
(9 Mohs with hard metal knife)
Feed grain size max.
BL: 50 mm
MI: 7 mm
BL: 50 mm
MI: 7 mm
MT/BT: 10 mm
Useable volume max.
BL: 2000 ml
MI: 250 ml / 400 ml
BL/DI: 2000 ml
MI: 250 ml/ 400 ml
MT: 150 ml
BT: 250 ml
Material of grinding vessels
BL: PCTG
MI: Stainless steel
BL / DI / MT / BT: PCTG
MI: Stainless steel
Material beater / cutter
BL / MI: Stainless steel
MI: Hard metal
BL / DI / MT / BT: Stainless steel
MI: Hard metal
Speed
Min. 3000 rpm
Max. 20 000 rpm
Min. 3000 rpm
Max. 20 000 rpm
Setting of operation time 0 – 5 min 0 – 5 min
Timer / Counter Yes Yes
Intermittent operation Yes Yes
Programmable No Yes
Cooling water connection by milling
chamber
Yes Yes
Milling with dry ice by milling chamber Yes Yes
Temperature measurement No Yes*
Vessel recognition No Yes*
Weighing function No Yes
GENERAL DATA
Voltage 220 – 240 V 220 – 240 V
Frequenz 50 / 60 50 / 60
Motor brushless brushless
Motor rating input 1 000 W 1000 W
Motor rating output 800 W 800 W
Display LCD TFT
USB interface Yes Yes
Bluetooth No Yes
Weight 10 kg 10 kg
Dimensions (W × H × D) 300 × 450 × 250 mm 300 × 450 × 250 mm
Permissible ambient temperature 5 – 40 °C 5 – 40 °C
Protection class according to DIN EN 60529 IP 31 IP 31
Technical data MultiDrive basic and control
* Only for vessels with "T"
BL: Blender vessel
MI: Milling chamber
DI: Dispering vessel
MT: Milling Tube
BT: Blender Tube
Scope of delivery may differ from illustrations
