IKA HBR 4 control 0020003549 [21/100] Interfaces and outputs
![IKA HBR 4 control 0020003549 [21/100] Interfaces and outputs](/views2/1545673/page21/bg15.png)
21
Interfaces and outputs
The device can be operated in “Remote” mode via an RS 232 using
the laboratory software Labworldsoft
®
.
Note: Please comply with the system requirements together with
the operating instructions and help section included with the soft-
ware.
Configuration
The RS 232 serial interface can be used to operate the device using
a computer and a suitable user program (Labworldsoft
®
).
In order to increase safety when operating the HBR 4 control
using a PC, a watchdog function can be activated which monitors
the continuous data flow (see section entitled: “Watchdog func-
tion”).
• The functions of the interface circuit between the laboratory de-
vice and the automation system are a selection from the signals
specified in the EIA standard RS 232 C as per DIN 66020 Part 1.
The assignment of the different signals can be seen in the image.
• Standard RS 232 C, corresponding to DIN 66259 Part 1 is valid
for the electronic characteristics of the interface circuits and as-
signment of signal states.
• Transmission process: asynchronous character transmission in
start-stop operation.
• Transmission type: full duplex
• Character format: character composition according to data for-
mat in DIN 66022 for start-stop operation. 1 start bit, 7 charac-
ter bits, 1 parity bit (even), 1 stop bit.
• Transmission speed: 9600 bit/s
• Data flow control: hardware handshake
• Access method: data transmission from the device to the com-
puter only occurs after a request from the computer.
Command syntax
The following points should be noted for the instruction set:
• Commands are generally sent from the computer (master) to the
lab device (slave).
• The device sends only at the computer’s request. Even fault in-
dications cannot be sent spontaneously from the device to the
computer (automation system).
• Commands and parameters, as well as consecutive parameters,
must be separated by at least one space (code: hex0x20).
• Each individual command (incl. parameters and data) and each
response are terminated with Blank CR LF (Code: hex 0x0D and
0x0A) and have a maximum length of 80 characters.
• The decimal separator in a number is a dot (Code: hex 0x2E).
The above details correspond as far as possible to the recommen-
dations of the NAMUR working party (NAMUR recommendations
for the design of electrical plug connections for analogue and
digital signal transmission on individual items of laboratory control
equipment, rev. 1.1).
Summary of available NAMUR commands
Abbreviations used:
X,y =
numbering parameter (integer)
m = variable value, integer
n = variable value, floating-point number
X = 1 Temperature of external sensor
X = 2 Bath temperature
X = 3 Bath safety temperature
X = 4 Speed
X = 52 External PT 1000 temperature sensor offset in K (-3.0 <= n <=+3.0 )
X = 54 Error 5 response time in minutes (1 <= n <= 30)
