Your Life, our Quality. Worldwide. 16 Residential
CCMMAA -- BB -- CC -- DD -- CCMMRR
SINGLE IMPELLER CENTRIFUGAL ELECTRIC PUMPS
in cast iron
C
ast iron self-priming electric pumps.
APPLICATIONS
• Pressure boosting domestic plants
•
Small-scale irrigation
• Moving non-aggressive liquids for civil and industrial use
• Washing plants
• Washing vehicles
TECHNICAL DETAILS
• Available with brass impeller (CMA 0.50 M GO, CMA 0.75 M GO,
CMA 1.00 M GO)
• The CMR version is equipped with an open impeller
• They can be inserted into machinery for industrial use
TECHNICAL DATA
• Maximum working pressure:
- 6 bar for CMA 0.50 - 0.75 - 1.00, CMB 0.75 - 1.00 - 1.50 - 2.00 -
3.00, CMC 0.75 - 1.00, CMD 1.50 - 2.00 - 3.00 - 4.00, CMR 0.75 -
1.00
- 8 bar for CMA 1.50 - 2.00 - 3.00, CMB 4.00 - 5.50
• Maximum temperature of the liquid:
- 40°C for CMA 0.50 - 0.75 - 1.00
- 90°C for the rest of the range
• Self-ventilated 2 pole asynchronous motor
• Class of insulation F
• IP44 Protection rating
• 230V ±10%, 50Hz single phase voltage,
230/400V ±10%, 50Hz three phase voltage
• Permanent capacitor inserted and thermo-amperometric protection
with automatic rearm incorporated for the single phase motor
• Protection under user's responsibility for the three phase version
• G1 suction connection for CMA 0.50 - 0.75 - 1.00,
G1¼ for CMA 1.50 - 2.00 - 3.00, G1½ for CMR, G2 for CMB - CMC,
G2½ for CMD
• G1 discharge connection for CMA, G1¼ for CMB, G1½ for CMR,
G2 for CMC, G2½ for CMD
MATERIALS
• Cast iron pump body
• Mechanical seal in Carbon/Ceramic/NBR
• Impeller:
- in PPO reinforced with fibreglass for CMA 0.50 - 0.75 - 1.00
- in brass for CMA 1.50 - 2.00 - 3.00, CMB 2.00 - 3.00 - 4.00 - 5.50,
CMR 0.75 - 1.00
- in cast iron for CMB 0.75 - 1.00 - 1.50, CMC, CMD
• Shaft:
- in AISI 303 for CMA 1.50 - 2.00 - 3.00, CMB 1.50 - 2.00 - 3.00,
CMD 1.50 - 2.00 - 3.00
- in AISI 304 for CMB 4.00 - 5.50, CMD 4.00
- in AISI 416 for CMA 0.50, CMR 0.75 - 1.00
- in AISI 420 for CMA 0.75 - 1.00, CMB 0.75 - 1.00, CMC 0.75 - 1.00
• Support:
- in aluminium for CMA 0.50 - 0.75 - 1.00, CMB 0.75 - 1.00,
CMC 0.75 - 1.00, CMR 0.75 - 1.00
- in cast iron for the rest of the range
CONTROL PANELS
• 1EPBH (see page 68)
CMA-B-C-D – CMR IDENTIFICATION CODE
CMB 1.50
T
0.50
0.75
P
OWER [HP]
M
M
ODEL
M
SINGLE PHASE
THREE PHASE
0.80
1.00
1.50
2.00
3.00
4.00
5.50
CMA
CMB
CMC
CMD
CMR
ACCESSORIES (on request)
• 5 litre 10 bar ¾ EPDM vessel
• 24 litre 8 bar 1” EPDM vessel
• 24 litre 10 bar 1” EPDM vessel
• PVC 5m key float with counter-weight
• PVC 10m key float with counter-weight
• SQUARE-D FSG-2 1.4÷4.6 bar G¼ F pressure switch
• FYG-22 2.8÷7 bar G¼ F pressure switch
• Presscomfort - Pressure regulator (see page 70)
• Press
•o•Matic - Variable speed control system
(230V±10% single phase - power supply three phase 220V output –
maximum motor power 2.2 kW - 3 HP - see page 71)
CMA-B-C-D
CMR
