IKA ICC basic pro 9 0008035100 [14/37] Heating and cooling

+ 200 °C- 30 °C

+ 100 °C

0 °C- 20 °C

HRC 2 basic

HRC 2 control

CBC 5 basic and control

///

NEW!

Heating and cooling

/// Heating and cooling in one

IKA has expanded its circulator portfolio by four new devices, adding the combined

refrigerated and heating circulators CBC 5 and HRC 2 devices (each in basic and

control variants). The temperature range is from - 30 °C to + 200 °C.

CBC 5 control

Refrigerated and

heating circulator

HRC 2 basic

Refrigerated and

heating circulator

HRC 2 control

Refrigerated and

heating circulator

CBC 5 basic

Refrigerated and

heating circulator

Temperature control productsTemperature control products
