NEW!
HRC 2 basic and control
/// Compact refrigerated and heating circulators
Launching the HRC 2, IKA is offering a compact refrigerated and heating circulator
with 400 W cooling power and 1,500 W heating power. It is best suited for tempering
small, external applications. Applications with larger pressure losses, e.g. lab reactors
or viscometers can be supplied with appropriate flow volume of bath fluid through
the more powerful pressure and suction pump (0.5 bar). With a level controller, it is
possible to temper samples in open baths.
The on-demand cooling unit runs quietly and with utmost eciency. Maximum cooling
performance is achieved if the easy-to-reach air filter is replaced routinely.
USB/RS 232 interfaces for connecting a
PC, using labworldsoft and enabling online
updates of device software.
Silent mode –
the fan only runs as needed.
HRC 2 control – connection option of exter-
nal solenoid valves via multi-IO port.
HRC 2 control – connector for external
PT 100 temperature probe.
Integrated transport handle on the
back of the device, recessed handles for
ergonomic transport.
SAFETY AND
CONVENIENCE FEATURES
› Adjustable safety circuit
› Filling level detection
› Visual and audible alarm
› RS 232 and USB interfaces
› Multi IO-port (control version only)
HRC 2 control – detachable WiCo
(wireless controller) for simple and safe
remote access from up to 10 m (30 ft.).
