Fluke 714 [6/15] Simulating a thermocouple
![Fluke 714 [6/15] Simulating a thermocouple](/views2/1005470/page6/bg6.png)
714 English Instruction Sheet
Page
6
Simulating a Thermocouple
714
THERMOCOUPLE
CALIBRATOR
TC
30V
MAX
Press to toggle
°C or °F
TC wire and
miniplug of same
type as selected
Press so that
OUTPUT is on
the display
Press to scroll
up/down 0.1°
(or 0.01 mV).
Hold down to
scroll faster
Press to step
up/down 50°
(or 10 mV)
Press to select
TC type or mV
Shows TC type
selected
OUTPUT
ke02f.eps
