25
Water filter
For instructions on the water softener filter, see the
section "INSTALLING THE FILTER".
TURNING THE APPLIANCE
OFF
Each time the appliance is turned off, it performs
an automatic rinse cycle which cannot be inter-
rupted.
Danger of burns!
During rinsing, a little
hot water flows from the coffee spouts.
Avoid contact with splashes of water.
To turn the appliance off, press the On-Off/stand-
by button (A7).
The appliance performs the rinse cycle then goes
off.
N.B.!
If the appliance is not used for an
extended period, place the main switch (A23) on
the back of the appliance in the 0 position.
TECHNICAL SPECIFICATION
Voltage: 220-240 V~ 50/60 Hz max. 10A
Absorbed power: 1350 W
Pressure: 15 bars
Water tank capacity: 1.8 litres
Size LxHxD: 594x 378/460x398 mm
Weight: 26 kg
The appliance complies with the follo-
wing EC directives:
• Low Voltage Directive 2006/95/EC and sub-
sequent amendments;
• EMC Directive 2004/108/EC and subsequent
amendments
Materials and accessories coming into contact
with food conform to European regulation (EC)
no. 1935/2004.
ELECTRICAL CONNECTION
(UK ONLY)
A) If your appliance comes fitted with a plug, it will
incorporate a 13 Amp fuse. If it does not fit your
socket, the plug should be cut off from the mains
lead, and an appropriate plug fitted, as below.
WARNING: Very carefully dispose of the cut
off plug after removing the fuse: do not in-
sert in a 13 Amp socket elsewhere in the
house as this could cause a shock hazard.
With alternative plugs not incorporating a
fuse, the circuit must be protected by a 15
Amp fuse. If the plug is a moulded-on type,
the fuse cover must be re-fitted when chan-
ging the fuse using a 13 Amp Asta approved
fuse to BS 1362. In the event of losing the
fuse cover, the plug must NOT be used until a
replacement fuse cover can be obtained from
your nearest electrical dealer. The colour of
the correct replacement fuse cover is that as
marked on the base of the plug.
B) If your appliance is not fitted with a plug,
please follow the instructins provided below:
WARNING - THIS APPLIANCE MUST BE EAR-
THED
IMPORTANT
The wires in the mains lead are coloured in ac-
cordance with the following code:
Green and yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead may
not correspond with the coloured markings iden-
tifying the terminals in your plug, proceed as fol-
lows:
The green and yellow wire must be connected to
the terminal in the plug marked with the letter E
or the earth symbol or coloured green or
green and yellow.
The blue wire must be connected to the terminal
marked with the letter N or coloured black.
The brown wire must be connected to the termi-
nal marked with the letter L or coloured red.
