BUILT-IN INSTALLATION
Verify the minimum measurements required for
correct installation of the appliance.
The coffee maker must be installed in a column
and the column must be firmly fixed to the wall
with commercially available brackets.
Important:
• Important: all installation or maintenance
operations must be performed with the ap-
pliance disconnected from the mains electri-
city supply.
• Kitchen furniture in direct contact with the
appliance must be heat resistant (65°C min).
• To guarantee correct ventilation, leave a gap
at the bottom of the cabinet (see measure-
ments in figure).
460 mm
594 mm
20 mm
398 mm
45 mm
45 m
m
45 mm
4
5 mm
450 + 2 mm
850 mm Min
500 mm
545 mm Min.
200 cm
2
560 + 8 mm
h 460 mm
h 378 mm
