Thank you for purchasing your DeVilbiss
DAGR
®
airbrush! You will find that this high
quality, versatile airbrush gives the
demanding professional artist the full range
of performance—from spraying fine lines to
wide backgrounds—with a wide range of
materials—from solvent-based automotive
paints to waterbase inks.
DAGR airbrushes are precision made with
micro machining and high quality
materials. Each airbrush is spray tested
before being packaged in its collector’s tin,
assuring that it meets the tough quality
standards you have come to expect from
DeVilbiss. With proper care, your DAGR
airbrush will provide you with excellent
performance to express your creativity.
SPECIFICATIONS
Operating Pressures:
20 to 50 psi
Maximum Inlet Pressure:
175 psi
Airbrush Plating:
Nickel, copper, chrome
Needle Packing:
PTFE (solvent-proof)
GET READY TO SPRAY
SAFETY FIRST
Please read all safety information on pages
8 and 9.
Connect to Compressed Air
Connect your DAGR airbrush to a
regulated air line or select an appropriate
compressor. The DeVilbiss Airblade
®
single piston compressor is a compact,
economical choice for the beginner and
will provide approximately 25-30 psi of air
pressure to the DAGR airbrush. At 35-40
psi, the DAGR will produce a high paint
flow for shadow, fade, and background
spray, as well as for detail work and fine
lines.
AIRBRUSH INSTRUCTIONS AND MAINTENANCE
by
Service Bulletin
SB-2-055-F
Replaces SB-2-055-E
