Page 7SB-2-055-F

Ref.

No. Order No. Model No. Description

1 802613 DGR-101 Crown cap

2 802615 DGR-103-35 Air cap (for .35mm nozzle)

3 802616 DGR-104 Head cap

4 802618 DGR-105-35 Nozzle (.35mm)

• 5 –– O-ring (head cap & handle)

6 802619 DGR-106K Packing and nut assembly (PTFE)

7 802620 DGR-107 Air valve casing

8 803644 DGR-308K Air valve kit

• 9 –– Air valve o-ring

10 –– Air valve plunger

11 –– Air valve spring

12 –– Air valve nut

13 803645 DGR-323 Trigger

Ref.

No. Order No. Model No. Description

15 802623 DGR-110K Needle guide, rocker, & spring

16 –– Needle guide and rocker

• 17 –– Needle spring

18 802624 DGR-111 Spring guide

19 802625 DGR-112 Needle locknut

20 802627 DGR-113-35 Needle (for .35mm nozzle)

21 802628 DGR-114 Cutaway handle w/pre-set

• 22 –– O-ring (pre-set needle knob)

23 802630 DGR-116 Pre-set needle knob

24 802631 DGR-117 1/4 oz.(7 cc) cup and lid

25 802632 DGR-118 1/3 oz.(9 cc) cup and lid (standard)

26 802633 DGR-119 1/2 oz.(14 cc) cup and lid

27 802634 DGR-120 Cup lid

28 802635 DGR-121K DAGR repair kit

30 802975 DGR-18-K5 O-ring (head cap & handle) kit (5)

Ref. Description Qty.

5 O-ring (head cap & handle) 3

9 Air valve o-ring 2

17 Needle spring 1

22 O-ring (pre-set needle knob) 1

• DAGR Repair Kit 802635 (DGR-121K) includes:
