![Ransburg 76652-03 [12/23] Table 1 comparison to 8333 00 sprayability meter with new multi function meter](/img/pdf.png)
Ransburg 76652-03 [12/23] Table 1 comparison to 8333 00 sprayability meter with new multi function meter
![Ransburg 76652-03 [12/23] Table 1 comparison to 8333 00 sprayability meter with new multi function meter](/views2/1548107/page12/bgc.png)
1 MW 155 Suitable
2 MW 150 Suitable
3 MW 147 Suitable
4 MW 145 Suitable
14 MW 140 Suitable
60 MW 135 Suitable
190 MW or .1 GW 130 Suitable
320 MW or .3 GW 125 Suitable
410 MW or .4 GW 120 Suitable
500 MW or .5 GW 115 Suitable
600 MW or .6 GW 110 Suitable
760 MW or .7 GW 105 Suitable
1020 MW or 1.0 GW 100 Suitable
1.1 GW 98 Test Sample Part
1.3 GW 95 Test Sample Part
1.5 GW 90 Test Sample Part
2.0 GW to Innity 85 or less Requires Surface Prep
TABLE 1 - COMPARISON TO 8333-00 SPRAYABILITY METER
WITH NEW MULTI-FUNCTION METER
8333-00 Sprayability
Meter Reading
Spray Condition
New 76652-01 Multi-Function
Meter Reading
Test Equipment - Introduction, Operation & Maintenance
TE-98-01.8
9
