Sterwins B40 [3/4] Right additional tine d25 straight blade 40x4
![Sterwins B40 [3/4] Right additional tine d25 straight blade 40x4](/views2/1551627/page3/bg3.png)
Rep
N°
Ref.
Désignation
Description
Moteur
Engine
MAv
MAr*
Qte
1 3002170301
CHASSIS COMPACT EVO NOIR RAL9005
FRAME OF COMPACT EVO BLACK RAL9005
1
1 3002170501
CHASSIS COMPACT EVO Gris (8120)
FRAME OF COMPACT EVO Grey (8120)
1
1 3002170601
CHASSIS COMPACT EVO Gris (627)
FRAME OF COMPACT EVO Gris (627)
1
1 3002171301
CHASSIS COMPACT EVO ROUGE RAL3002
FRAME OF COMPACT EVO RED RAL3002
1
2 3001000027
CART 1/5 JONC xGRIS8x /Jt Bleu/Ch Elite
Transmission, Grey flanged
1
3 3002000107
SUPPORT ROUE FIL DIA14 ZNCR3
TRANSPORT WHEEL SUPPORT WIRE D14 ZNCR3
1
4 3002170302
PLAT POTENCE GUID 40x6 NOIR RAL9005
HANDLEBAR BRACKET 40x6 BLACK RAL9005
2
4 3002170502
PLAT POTENCE GUID 40x6 Gris (8120)
HANDLEBAR BRACKET 40x6 Grey (8120)
2
4 3002170602
PLAT POTENCE GUID 40x6 Gris (627)
HANDLEBAR BRACKET 40x6 Gris (627)
2
4 3002171302
PLAT POTENCE GUID 40x6 ROUGE RAL3002
HANDLEBAR BRACKET 40x6 RED RAL3002
2
5 3002110308
GUIDON GAUCHE COMPACT x Noir ENTRAXE 500MM
LEFT HANDELBAR x BLACK WITH GAP 500MM
1
5 3002110508
GUIDON GAUCHE COMPACT x G8120 ENTRAXE 500MM
LEFT HANDELBAR x GREY (8120) WITH GAP 500MM
1
5 3002110608
GUIDON GAUCHE COMPACT x G627 ENTRAXE 500MM
LEFT HANDELBAR x GREY (627) WITH GAP 500MM
1
5 3002110708
GUIDON GAUCHE COMPACT x G8201 ENTRAXE 500MM
LEFT HANDELBAR x GREY (8201) WITH GAP 500MM
1
5 3002112708
GUIDON GAUCHE COMPACT x G7040 ENTRAXE 500MM
LEFT HANDELBAR x GREY RAL7040 WITH GAP 500mm
1
6 3002110309
GUIDON DROIT COMPACT x Noir ENTRAXE 500MM
RIGHT HANDELBAR x BLACK WITH GAP 500MM
1
6 3002110509
GUIDON DROIT COMPACT x G8120 ENTRAXE 500MM
RIGHT HANDELBAR x GREY (8120) WITH GAP 500MM
1
6 3002110609
GUIDON DROIT COMPACT x G627 ENTRAXE 500MM
RIGHT HANDELBAR x GREY (627) WITH GAP 500MM
1
6 3002110709
GUIDON DROIT COMPACT x G8201 ENTRAXE 500MM
RIGHT HANDELBAR x GREY (8201) WITH GAP 500MM
1
6 3002172709
GUIDON DROIT COMPACT x G7040 ENTRAXE 500MM
RIGHT HANDELBAR x GREY RAL7040 WITH GAP 500MM
1
7 3002000302
EPERON PRIMO NOIR RAL9005
SPUR FOR PRIMO BLACK RAL9005
1
8 3002170303
TOLE PROTECTION DROITE NOIR RAL9005
RIGHT TINE GUARD COMPACT EVO BLACK RAL9005
1
8 3002170503
TOLE PROTECTION DROITE Gris (8120)
RIGHT TINE GUARD COMPACT EVO Grey (8120)
1
8 3002170603
TOLE PROTECTION DROITE Gris (627)
RIGHT TINE GUARD COMPACT EVO Grey (627)
1
8 3002171303
TOLE PROTECTION DROITE ROUGE RAL3002
RIGHT TINE GUARD COMPACT EVO RED RAL3002
1
8 3002173503
TOLE PROTECTION DROITE GRIS RAL7000
RIGHT TINE GUARD COMPACT EVO Grey RAL7000
1
9 3002170304
TOLE PROTECTION GAUCHE NOIR RAL9005
LEFT TINE GUARD COMPACT EVO BLACK RAL9005
1
9 3002170504
TOLE PROTECTION GAUCHE Gris (8120) LEFT TINE GUARD COMPACT EVO Grey (8120)
1
9 3002170604
TOLE PROTECTION GAUCHE Gris (627) LEFT TINE GUARD COMPACT EVO Grey (627)
1
9 3002171304
TOLE PROTECTION GAUCHE ROUGE RAL3002
LEFT TINE GUARD COMPACT EVO RED RAL3002
1
9 3002173504
TOLE PROTECTION GAUCHE GRIS RAL7000
LEFT TINE GUARD COMPACT EVO Grey RAL7000
1
10 3002170101
LEVIER D'EMB COMPACT EVO
PLATE FOR CLUTCH LEVER
1
11 8300000101
KIT INVERSEUR MOTOB (06-2012)
KIT REVERSE GEAR BOX (06-2012)
1
12 0503000080
ETIQ. "NIVEAU DE BRUIT" 100 dB
STICKER NOISE LEVEL '100Db'
750 series/800 series/GX160/Lc/R180
1
12 0503000079
ETIQ. "NIVEAU DE BRUIT" 98 dB
Sticker noise lever '98Db'
EP/GC
1
12 0503000062
"ETIQ. ""NIVEAU DE BRUIT"" 93
STICKER NOISE LEVEL '93Db'
GT400/550 series/GX120
1
13 0503000077
ETIQ. "SECURITE" 31x31 MM PROTECTION AUDITIVE
SAFTY STICKER EARS PROTECTION
1
14 0503000045
ETIQ. POIGNEE GAZ (AVEC STOP)
STICKER THROTTLE CONTROL STOP-MIN-MAX
1
15 0503000043
ETIQ. GAZ (SS STOP)VERS PNEUM DIM 42X11
Label throttle control without stop
GX/Lc170/R180 1
16 0503000036
"ETIQ. ""SECURITE 5 LOGOS""Xce
STICKER SECURITY
1
17 0503000031
"ETIQ. ""MARCHE/ARRET""/SWITCH DIM 20 X 15
STICKER SWITCH ON/OFF GX
1
18 0341000037
POIGNEE PLASTIQUE DIAM 25 CB
HAND SIDE GRIP
2
19 0341000007
POULIE POLYA. xINV MECAx
TRANSMISSION PULLEY
1
20 0341000003
GALET 2 EPAULEMENTS ROUL 6200 ZZ
CLUTCH RUNNER ROUL 6200 ZZ
1
21 0340010093
CACHE INT COMPACT EVO MAR
PLASTIC COVER PLATE COMPACT EVO (REVERSE)
MAr
1
21 0340010065
CACHE INT COMPACT xMAVx
PLASTIC COVER PLATE COMPACT
MAv
1
22 0340010092
EXTENTION TOLE PROT COMPACT EVO NOIR RAL9005
ADD. TINE GUARD xBLACK RAL9005
2
22 0340010094
EXTENTION TOLE PROT COMPACT EV ROUGE RAL3002
ADD. TINE GUARD COMPACT EVO RED RAL3002
2
22 0340010095
EXTENTION TOLE PROT COMPACT EV GRIS RAL7040
ADD. TINE GUARD COMPACT EVO GREY RAL7040
2
22 0340010096
EXTENTION TOLE PROT COMPACT EV ORANGE RAL2009
ADD. TINE GUARD COMPACT EVO ORANGE RAL2009
2
22 0340010099
EXTENTION TOLE PROT COMPACT EV GRIS RAL7000
ADD. TINE GUARD COMPACT EVO GREY RAL7000
2
22 0340010101
EXTENTION TOLE PROT COMPACT EV BLEU RAL5010
ADD. TINE GUARD COMPACT EVO BLUE RAL5010
2
22 0340010102
EXT TOLE PROT COMPACT EVO VERT RAL6029
ADD. TINE GUARD COMPACT EVO GREEN RAL6029
2
23 0340010071
CAPOT COURROIE MBR NOIR RAL9005
BELT COVER BLACK RAL9005 MBR
1
24 0340010005
CAPOT COURROIE ECO+99 xBLEU RAL5010
BELT COVER BLUE RAL5010 COMPACT
1
24 0340010006
CAPOT COURROIE ECO+99 xNOIRx
BELT COVER BLACK RAL9005 COMPACT
1
24 0340010007
CAPOT COURROIE ECO+99 xORANGE RAL2009
BELT COVER ORANGE RAL2009
1
24 0340010008
CAPOT COURROIE ECO+99 xROUGE RAL3001
BELT COVER RED RAL3001 COMPACT
1
24 0340010009
CAPOT COURROIE ECO+99 xVERT RAL6029x
BELT COVER GREEN RAL6029 COMPACT
1
24 0340010049
CAPOT COURROIE ECO+99 ORANGE P165x
Belt cover orange P165
1
24 0340010072
CAPO COUR ECO+99 ROUGE RAL3020
BELT COVER RED RAL3020 COMPACT
1
24 0340010073
CAPOT COURROIE ECO+99 ORANGE P1375C
BELT COVER ORANGE P1375c COMPACT
1
24 0340010090
CAPOT COURROIE ECO+99 JAUNE P116x
Belt cover yellow P116
1
24 0340010100
CAPOT COURROIE ECO+99 GRIS RAL7000
BELT COVER Grey RAL7000 COMPACT
1
25 0330012006
SWITCH STOP GX
Switch engine cut-off
GX/R180
1
25 0330062001
SWITCH ON/OFF LONCIN SWITCH ON/OFF LONCIN
Lc
1
26 0330012003
GRILLE ECHAP GX120/GX160
EXHAUST GRILL GX120/GX160
1
26 0330032001
GRILLE ECHAPPEMENT EP
EXHAUST GRILL EP
1
26 0330062003
GRILLE ECHAPP LONCIN 212cc
EXHAUST GRILL LONCIN 212cc
1
26 0330082002
GRILLE ECHAPP GT400
EXHAUST GRILL GT400
1
26 0330092001
GRILLE ECHAPP RT180-3
Exhaust grill R180-3
1
27 0320010016
FRAISE ADDIT STD 40X4 GAUCHE
LEFT ADDITIONAL TINE D25 STRAIGHT BLADE (40X4)
2
28 0320010015
FRAISE ADDIT STD 40X4 DROIT
RIGHT ADDITIONAL TINE D25 STRAIGHT BLADE (40X4)
2
29 0320010014
FRAISE DEPART DEM STD 40X4 GAUCHE
LEFT TINE REMOVABLE D25 STRAIGHT BLADE (40X4)
1
30 0320010013
FRAISE DEPART DEM STD 40X4 DROIT
RIGHT TINE REMOVABLE D25 STRAIGHT BLADE (40X4)
1
31 0320010001
DISQUE D25 PRIMO
DISK D25
2
32 0309000030
ROUE 200 ALES 14 MOY 60 NOIR
BLACK WHELL D200 BORE 14 LG.60
1
33 0308040052
CABLE GAZ x1250 xLF60 Z0° MANETTE LGC
Throttle cable Lg 1250mm stroke 60mm
GT/800 series/GC
1
33 0308040050
CABLE GAZ x1050 xLF60 Z0° MANETTE LGC
Throttle cable Lg 1050mm stroke 60mm
EP/500 & 750series/GX/Lc/RATO
1
34 0308020052
CABLE EMB Lg 1050 CF 133 LAKS EMB CLIP
CLUTCH CABLE LG1050 CF133 LAKS LEVER x CLIP TIP
1
35 0308010005
CABLE INVERS VITESSE Motob LAB
SELECT SPEED CABLE LAB HANDLEVER
MAr
1
36 0307020023
MANETTE GAZ LGC POMMEAU NOIR RAL9005
THROTTLE LEVER LGC BLACK KNOB RAL9005
2
37 0307010032
LEVIER EMB LAB C20 ECROU M6 TEMPO MAR
lever LAB Ø25 stroke 20
MAr
1
38 0307010030
LEVIER EMB LAKS C27 ECROU M6 TEMPO EMBRAYAGE
HANDLEVER LAKS C27 NUT M6 CLUTCHING SYMBOL
1
39 0306060021
POULIE MOT D65 ALES 19,06
Engine pulley Ø65 bore Ø19.06
GC135
1
39 0306060005
POULIE MOT D55 ALES 19,06
ENGINE PULLEY D55 BORE Ø19,06
1
40 0306050001
ARBRE PRIMAIRE CANNELE MAV
FORWARD GEAR SHAFT MAV
MAv
1
41 0306030024
COURROIE Gts A40 BBK
Belt Gts A40
GC135
1
41 0306030002
COURROIE BAREBACK 6841 Gts A39 BBK
BELT BAREBACK 6841Gts A39 BBK
1
*MAv=Marche Avant / Forward running
MAr=Marche Arrière / Reverse running
