7) Wiring and Connections
SWC
Rear audio output (Left) /
White
Red
2 Channel Amplier
Black
Black
Black
Black
Rear audio output (Right) /
Steering wheel
control terminal
Subwoofer output 1
Subwoofer output 2
Antenna
(Black)
A
B
2
4
6
8
1
3
5
7
1
3
5
7
2
4
6
8
C
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
Refer to next page
• Connecting to the external amplier
External ampliers can be connected to the 2 channel RCA output connections.
Ensure that the connectors are not grounded or shorted to prevent damage to the
unit.
8) Connecting the Accessories
For VW and Audi: Change wiring like above.
A
B
C
16
14
12
10
8
6
4
2
15
13
11
9
7
5
3
1
1
3
5
7
2
4
6
8
1
3
5
7
2
4
6
8
Rear right -
Front right -
Front left +
Rear left +
AMP Remote
ACC +
Ground
Rear right +
Front right +
Front left -
Rear left -
Phone Mute
Battery +
/FUSE15A
Phone Mute / Brown Rear right (+) / Purple
Rear right (-) / Purple with black stripe
Front right (+) / Gray
Battery 12V(+) / Yellow
Front right (-) / Gray with black stripe
Remote On / Blue with white stripe
Front left (+) / White
Front left (-) / White with black stripe
ACC+ / Red Rear left (+) / Green
Ground / Black Rear left (-) / Green with black stripe
YellowYellow
Red Red
Function
Connector A Connector B
Location
