28
TASCAM US-16x08
11 – Specifications
Specifications
Ratings
8
Sampling frequencies
44.1/48/88.2/96 kHz
8
Quantization bit depth
16-bit or 24-bit
Analog inputs
8
IN 1-8 mic inputs (balanced)
Connector: XLR-3-31 equivalent
(1: GND, 2: HOT, 3: COLD)
Input impedance: 2.4 kΩ
Nominal input level: −68 dBu (0.0003 Vrms)
(gain knob at maximum)
Nominal input level: −12 dBu (0.195 Vrms)
(gain knob at minimum)
Maximum input level: +8 dBu (1.947 Vrms)
Gain range: 56 dB
8
IN 9-10 instrument inputs (unbalanced)
(LINE/INST switch set to INST)
Connectors: 6.3mm (1/4") standard TS jacks
(Tip: HOT, Sleeve: GND)
Input impedance: 1 MΩ or more
Nominal input level: −57 dBV (0.0014 Vrms)
(gain knob at maximum)
Nominal input level: −12 dBV (0.251 Vrms)
(gain knob at minimum)
Maximum input level: +8 dBV (2.512 Vrms)
Gain range: 45 dB
8
IN 9-10 line inputs (balanced)
(LINE/INST switch set to LINE)
Connectors: 6.3mm (1/4") standard TRS jacks
(Tip: HOT, Ring: COLD, Sleeve: GND)
Input impedance: 10 kΩ
Nominal input level: −41 dBu (0.0069 Vrms)
(gain knob at maximum)
Nominal input level: +4 dBu (1.228 Vrms)
(gain knob at minimum)
Maximum input level: +24 dBu (12.282 Vrms)
Gain range: 45 dB
8
LINE IN 11-16 line inputs (unbalanced)
(LEVEL switch set to “−10dBV")
Connectors: 6.3mm (1/4") standard TS jacks
(Tip: HOT, Sleeve: GND)
Input impedance: 10 kΩ
Nominal input level: −10 dBV (0.3162 Vrms)
Maximum input level: +10 dBV (3.162 Vrms)
8
LINE IN 11-16 line inputs (balanced)
(LEVEL switch set to “+4dBu")
Connectors: 6.3mm (1/4") standard TRS jacks
(Tip: HOT, Ring: COLD, Sleeve: GND)
Input impedance: 10 kΩ
Nominal input level: +4 dBu (1.228 Vrms)
Maximum input level: +24 dBu (12.282 Vrms)
Analog outputs
8
LINE OUT 1-8 line outputs (balanced)
Connectors: 6.3mm (1/4") standard TRS jacks
(Tip: HOT, Ring: COLD, Sleeve: GND)
Output impedance: 100 Ω
Nominal output level: +4 dBu (1.228 Vrms)
Maximum output level: +24 dBu (12.277 Vrms)
8
PHONES output
Connector: 6.3mm (1/4") standard stereo jack
Maximum output: 70 mW + 70 mW
(THD+N 1% or less, into 32 Ω load)
8
Frequency response
8
Input w PHONES output
At 44.1 kHz and 48 kHz
20 Hz – 20 kHz: ±1.0 dB (JEITA), supports Hi-Res
At 88.2kHz and 96kHz
20 Hz – 40 kHz: ±2.0 dB (JEITA), supports Hi-Res
Control input/output ratings
8
MIDI IN connector
Connector: 5-pin DIN
Format: standard MIDI
8
MIDI OUT connector
Connector: 5-pin DIN
Format: standard MIDI
8
USB
Connector: 4-pin USB B-type
Transfer rate: USB 2.0 High Speed (480 Mbps)
