![Tascam US-16x08 [7/34] Installing the mac os x settings panel](/views2/1553321/page7/bg7.png)
TASCAM US-16x08
7
3 – Installation
5. Next, select a language and click the “OK” button.
6. When the Setup Wizard screen appears, click the “Next”
button.
7. Read the contents of the License Agreement, and select
“Agree (A)” if you agree to the terms. Then, click the “Next”
button.
8. Next, click the “Install (I)” button.
9. When the Install Wizard screen appears, click the “Next (N)”
button.
10. Next, click the “Install (I)” button to start installation.
11. Click the “Finish” button when the screen below appears.
12. The following screen appears when installation has
completed. Click the “Finish (F)” button.
The installer will quit and the Settings Panel will launch.
CAUTION
•
When installing the driver, a warning might appear with a
message such as, “The software you are installing for the
hardware has not passed Windows Logo testing to verify its
compatibility with Windows.” If this message appears, click
“Continue Anyway” to proceed with the installation.
Installing the Mac OS X Settings Panel
NOTE
•
Install the Settings Panel on the computer before
connecting the unit to it with the USB cable. If the unit is
connected by the USB cable, cancel driver installation and
disconnect it before starting driver installation again.
•
During Settings Panel installation a warning message
like this might appear: “US-16x08.pkg can't be opened
because it was not downloaded from the Mac App Store.”
If a message like this appears, follow the instructions in
“Working with Gatekeeper” on page 8 in this manual
and then proceed with the installation.
8
Installation procedures
1. Download the latest Settings Panel for the operating system
you are using from the TEAC Global Site (http://teac-global.
com/) and save it on the computer to be used with the unit.
2. Double-click “US-16x08_X.XX.dmg", which is the saved disk
image file for the Settings Panel, and double-click “US-16x08.
pkg” inside the folder that opens.
NOTE
Depending on the computer’s settings, the downloaded zip
file might not have opened automatically. In this case, open
the zip file first and then double-click the disk image file.
