12
TASCAM US-1x2
5 – Using the Settings Panel
Opening the Settings Panel
You can use the Settings Panel to make settings for the various
functions of this unit.
You can open the Settings Panel in the following ways.
Windows
Windows 10
0
Click the Windows Start button, select “All Apps” and then
select “US-1x2 Settings Panel” under “TASCAM”.
Windows 8.1
0
Right-click the Windows Start button and select Control Pan-
el.
NOTE
You can also left-click the Start button to open the Start
screen. Then, click the button to open the Apps screen,
and select “US-1x2 Settings Panel” under “TASCAM”.
Windows 7
0
Click the Windows Start button, select “All Programs” and
then select “US-1x2 Settings Panel” under “TASCAM”.
Mac
0
Using the “Finder”, open the “Applications” folder and click
“US-1x2_SettingsPanel” to open the Settings Panel.
0
In the “Audio Devices” window of the “Audio MIDI Setup”
application, right-click (control-click) “US-1x2” (or click the
settings icon when the unit name is selected) and click “Con-
figure device…” to open the Settings Panel.
Windows Settings Panel overview
The Windows Settings Panel has three pages. Click a tab at the
top of the Settings Panel to open that page.
Home: This page shows a variety of information and allows
the selection of presets suitable for specific opera-
tions.
Settings: Make detailed settings for the US-1x2 on this page.
Custom: Make software mixer settings.
Home page
1 Status display area
This shows the current status of the software.
Item displayed Meaning
Software Ver. This is the software version.
Sample Rate This shows the sampling frequency.
Firmware Ver.
This is the firmware version used by the
connected unit.
Device
This is the name of the connected unit.
(“No Device” is shown when no device is
connected.)
2 Operating Mode
This selects the operation mode of the unit.
Options
DAW
Select this when using DAW software, as well as when
you do not need “
BROADCAST/KARAOKE
” mode (for live
broadcasting or karaoke applications).
BROADCAST/KARAOKE
Select this for live broadcasting, karaoke and similar
applications.
This preset enables the loopback function. It mixes the
sound output from the computer with the sounds in-
put through the IN1, IN2 and LINE IN L-R jacks on the
unit and sends the mix back to the computer.
TALKING
Select this for voice calling and similar applications.
This preset disables the loopback function. The sound
output from the computer (including received voices
and music playing on the computer) is not sent back to
the computer.
CUSTOM
Select this to use the settings made on the “
Custom
”
page.
