14
TASCAM US-1x2
5 – Using the Settings Panel
Custom page
1 IN 1 volume slider
Use to adjust the volume input through the unit's IN1 jack.
2 Input selection
Use to set whether the input signal is handled as “Mono” or
“Stereo”.
Options
Mono
When using one mic (connected to the IN1 jack), it will
be treated as input from both “IN 1” and “IN 2”.
The audio from “IN 1” will be heard from both left and
right headphone channels.
In most circumstances, select this when using a mic for
a live broadcast, for example.
Stereo
Even when using one mic (connected to the IN1 jack),
it will not be treated as being input from both “IN 1”
and “IN 2”.
It will be treated as only being input from “IN 1”.
The audio from “IN 1” will be heard from the left head-
phone channel, and audio from “IN 2” will be heard
from the right headphone channel.
Use this if a keyboard or other stereo audio sources is
being input for live broadcasting or karaoke.
NOTE
When DAW mode is selected, if set to “Mono”, this will auto-
matically be switched to “Stereo”.
3 IN 2 volume slider
Use to adjust the volume input through the unit's IN2 jack.
4 PC Audio Out volume slider
Use to adjust the playback volume of Windows Media Player
and karaoke apps.
5 BROADCAST Volume slider
Use to adjust the playback volume of Sound Recorder and ka-
raoke apps. Use this also to adjust the broadcast volume with
live broadcast apps.
NOTE
Double-click a volume slider to reset it to its default value.
6 Output
Use to set whether the output signal is handled as “Mono” or
“Stereo”.
Options
Mono
Only the audio from the left side can be handled when
using some applications. When using an application
like this, audio from the right side cannot be transmit-
ted or recorded.
Set to “Mono” to mix both left and right signals to
mono and transmit that sound to the computer.
Stereo
Set when the application being used supports stereo.
When set to “Stereo”, a stereo sound can be transmit-
ted to the computer.
NOTE
When set to “Mono”, all stereo input signals will be converted
to mono. This setting receives priority even if the “Input” se-
lection (2) is set to “Stereo” for mic input.
7 Mic Monitor selection
If the “Mic Monitor” checkbox has a check, sounds from mic
and other input will be mixed with the “PC Audio Out” signal
and looped back to the computer.
If the check is removed from the “Mic Monitor” checkbox,
sounds from mic and other sources input through IN 1 and
IN 2 will not be sent to the headphone output.
8 Loopback selection
If the “Loopback” checkbox has a check, the sound from the
computer will be broadcast and output from the PHONES
jack.
If the check is removed from the “Loopback” checkbox,
the sound from the computer will only be output from the
PHONES jack.
9 External Effects (ASIO)
To use an echo on mics and other signals input to the unit by
using an external effect, check the “External Effects (ASIO)”
checkbox.
CAUTION
Depending on the broadcast software settings, the signal
could loop and cause feedback.
NOTE
Even if you have removed the check from the “External Ef-
fects (ASIO)” checkbox, the check will automatically be added
when you select DAW mode.
0 External Effects switch
When a check is in the “External Effects (ASIO)” checkbox,
this switch will be set to the “External Effects” side and light.
q Custom Save
Click to save the “Custom” page settings.
You can use these settings when the “Operating Mode” item
is set to “Custom” on the “Home” page.
