Installing the drive 47
ACH550-01 User's Manual
Power wiring (IP54)
1. Remove the rubber cable seals and cut adequate holes into
them for the 1) power, 2) motor, and 3) control cables. The
conical part of the seals must face downwards when the
seals are inserted in the lead-through plate holes.
3
2
1
