14 ACH550 BACnet User’s Manual
Start-up
Relay Output Control
Using the fieldbus for relay output control requires:
• Drive parameter values set as defined below.
• Only make these drive programming changes if you require control via BACnet.
• Fieldbus controller supplied, binary coded, relay command(s) in the appropriate
location.
1. More than 3 relays requires the addition of a relay extension module.
Analog Output Control
Using the fieldbus for analog output control requires:
• Drive parameter values set as defined below.
• Fieldbus controller supplied analog value(s) in the appropriate location.
Communication Fault
When using fieldbus control, specify the drive’s action if serial communication is lost.
Drive Parameter Value Description
BACnet
Access Point
1401 RELAY OUTPUT 1 COMM (35) Relay Output 1 controlled by fieldbus. BO0
1402
RELAY OUTPUT 2 COMM (35) Relay Output 2 controlled by fieldbus. BO1
1403 RELAY OUTPUT 3 COMM (35) Relay Output 3 controlled by fieldbus. BO2
1410
1
RELAY
OUTPUT 4 COMM (35) Relay Output 4 controlled by fieldbus. BO3
1411
1
RELAY
OUTPUT 5 COMM (35) Relay Output 5 controlled by fieldbus. BO4
1412
1
RELAY OUTPUT 6 COMM (35) Relay Output 6 controlled by fieldbus. BO5
Drive Parameter Value Description
BACnet
Access Point
1501 AO1 CONTENT SEL 135 (COMM VALUE 1) Analog Output 1 controlled by
writing to parameter 0135.
AO0
1507
AO2 CONTENT SEL 136 (COMM VALUE 2) Analog Output 2 controlled by
writing to parameter 0136.
AO1
Drive Parameter Value Description
3018
COMM FAULT FUNC 0 (NOT SEL)
1 (
FAULT)
2 (
CONST SP7)
3 (
LAST SPEED)
Set for appropriate drive response.
3019 COMM FAULT TIME Set time delay before acting on a communication loss.
