ACH550 BACnet User’s Manual 21
Technical Data
Statement
This statement is part of this Standard and is required for its use.
BACnet Protocol Implementation Conformance Statement
Date: November 1, 2006
Vendor Name: ABB, Inc.
Product Name: Low Voltage AC Motor Drive
Product Model Number: ACH550
Applications Software Version: 0506
Firmware Revision: 310D
BACnet Protocol Revision: 4
Product Description:
The ACH550 is a high-performance adjustable frequency drive
specifically designed for commercial automation applications. This
product supports native BACnet, connecting directly to the MS/TP LAN.
All standard MS/TP baud rates are supported, as well as master mode
functionality. Over BACnet, the drive can be fully controlled as a standard
adjustable frequency drive. In addition, up to 16 configurable I/O ports
are available over BACnet for user applications.
BACnet Standardized Device Profile
(Annex L):
BACnet Operator Workstation (B-OWS)
BACnet Building Controller (B-BC)
BACnet Advanced Application Controller (B-AAC)
⌧ BACnet Application Specific Controller (B-ASC)
BACnet Smart Sensor (B-SS)
BACnet Smart Actuator (B-SA)
List all BACnet Interoperability Building
Blocks Supported (Annex K):
DS-RP-B, DS-WP-B, DM-DDB-B, DM-DOB-B, DM-DCC-B, DM-RD-B.
Segmentation Capability:
Segmented requests supported. Window Size ____
Segmented responses supported. Window Size ____
Standard Object Types Supported:
An object type is supported if it may be
present in the device. For each standard
Object Type supported provide the following
data:
1) Whether objects of this type are
dynamically creatable using the
CreateObject service
2) Whether objects of this type are
dynamically detectable using the
DeleteObject service
3) List of the optional properties supported
4) List of all properties that are writable
where not otherwise required by this
standard
5) List of proprietary properties and for each
its property identifier, data type, and
meaning
6) List of any property range restrictions
See table at "Object/Property Support Matrix" on page 23.
