Danfoss VLT Midi Drive FC-280PK37 [29/92] Pid control
![Danfoss VLT Midi Drive FC-280PK37 [29/92] Pid control](/views2/1557235/page29/bg1d.png)
2.5 PID Control
2.5.1 Speed PID Control
Parameter 1-00 Conguration Mode
Parameter 1-01 Motor Control Principle
U/f
VVC
+
[1] Speed closed loop
Not available
1)
Active
Table 2.5 Control Congurations, Active Speed Control
1) Not available indicates that the
specic mode is not available at all.
The following parameters are relevant for the speed control:
Parameter Description of function
Parameter 7-00 Speed PID Feedback Source Select from which input the speed PID gets its feedback.
Parameter 7-02 Speed PID Proportional Gain The higher the value, the quicker the control. However, too high a value may lead to
oscillations.
Parameter 7-03 Speed PID Integral Time Eliminates steady state speed error. Lower values mean quicker reaction. However, too low
a value may lead to oscillations.
Parameter 7-04 Speed PID Dierentiation Time Provides a gain proportional to the rate of change of the feedback. A setting of 0 disables
the dierentiator.
Parameter 7-05 Speed PID Di. Gain Limit If there are quick changes in reference or feedback in a given application, which means
that the error changes swiftly, the dierentiator may soon become too dominant. This is
because it reacts to changes in the error. The quicker the error changes, the stronger the
dierentiator gain is. The dierentiator gain can thus be limited to allow setting of the
reasonable dierentiation time for slow changes and a suitably quick gain for quick
changes.
Parameter 7-06 Speed PID Lowpass Filter Time A low-pass lter that dampens oscillations on the feedback signal and improves steady
state performance. However, too long a lter time deteriorates the dynamic performance of
the speed PID control.
Practical settings of parameter 7-06 Speed PID Lowpass Filter Time taken from the number of
pulses per revolution on from encoder (PPR):
Encoder PPR Parameter 7-06 Speed PID Lowpass Filter
Time
512 10 ms
1024 5 ms
2048 2 ms
4096 1 ms
Table 2.6 Speed Control Parameters
Product Overview Design Guide
MG07B102 Danfoss A/S © 03/2016 All rights reserved. 27
2 2
