4.5.1 Main Menu

Structure

0-** Operation / Display

0-0* Basic Settings

0-01 Language

0-03 Regional Settings

0-04 Operating State at Power-up

0-06 GridType

[10] >380-440V/50Hz/IT-grid<

[11] >380-440V/50Hz/Delta<

[12] >380-440V/50Hz<

[20] >440-480V/50Hz/IT-grid<

[21] >440-480V/50Hz/Delta<

[22] >440-480V/50Hz<

[110] >380-440V/60Hz/IT-grid<

[111] >380-440V/60Hz/Delta<

[112] >380-440V/60Hz<

[120] >440-480V/60Hz/IT-grid<

[121] >440-480V/60Hz/Delta<

[122] >440-480V/60Hz<

0-07 Auto DC Braking

0-1* Set-up Operations

0-10 Active Set-up

*[1] >Set-up 1<

[2] >Set-up 2<

[9] >Multi Set-up<

0-11 Programming Set-up

0-12 Link Setups

0-16 Application Selection

*[0] None

[1] >Process Close Loop<

[2] >Local/Remote<

[3] >Speed Open Loop<

[4] >Speed Close Loop<

[5] >Multi Speed<

0-2* LCP Display

0-20 Display Line 1.1 Small

0-21 Display Line 1.2 Small

0-22 Display Line 1.3 Small

0-23 Display Line 2 Large

0-24 Display Line 3 Large

0-3* LCP Custom Readout

0-30 Custom Readout Unit

0-31 Custom Readout Min Value

0-32 Custom Readout Max Value

0-37 Display Text 1

0-38 Display Text 2

0-39 Display Text 3

0-4* LCP Keypad

0-40 [Hand on] Key on LCP

0-42 [Auto on] Key on LCP

0-44 [Off/Reset] Key on LCP

0-5* Copy/Save

0-50 LCP Copy

*[0] >No copy<

[1] >All to LCP<

[2] >All from LCP<

[3] >Size indep. from LCP<

0-51 Set-up Copy

*[0] >No copy

[1] >Copy from setup 1<

[2] >Copy from setup 2<

[9] >Copy from Factory setup<

0-6* Password

0-60 Main Menu Password

1-** Load and Motor

1-0* General Settings

1-00 Configuration Mode

[0]* >Open Loop<

[1] >Speed closed loop<

[3] >Process Closed Loop<

[4] >Torque open loop<

[6] >Surface Winder<

[7] >Extended PID Speed OL<

[9] >Central Winder<

[10] >Positioning<

[11] >Synchronisation<

1-01 Motor Control Principle

[0] >U/f<

*[1] >VVC+<

1-03 Torque Characteristics

*[0] >Constant torque<

[1] >Variable Torque<

[2] >Auto Energy Optim. CT<

1-06 Clockwise Direction

1-08 Motor Control Bandwidth

1-1* Motor Selection

1-10 Motor Construction

1-14 Damping Gain

1-15 Low Speed Filter Time Const.

1-16 High Speed Filter Time Const.

1-17 Voltage filter time const.

1-2* Motor Data

1-20 Motor Power

[2] >0.12 kW - 0.16 hp<

[3] >0.18 kW - 0.25 hp<

[4] >0.25 kW - 0.33 hp<

[5] >0.37 kW - 0.5 hp<

[6] >0.55 kW - 0.75 hp<

[7] >0.75 kW - 1 hp<

[8] >1.1 kW - 1 hp<

[9] >1.5 kW - 2 hp<

[10] >2.2 kW - 3 hp<

[11] >3 kW - 4 hp<

[12] >3.7 kW - 5 hp<

[13] >4 kW - 5.4 hp<

[14] >5.5 kW - 7.5 hp<

[15] >7.5 kW - 10 hp<

[16] >11 kW - 15 hp<

[17] >15 kW - 20 hp<

[18] >18.5 kW - 25 hp<

[19] >22 kW - 30 hp<

[20] >30 kW - 40 hp<

[21] >37 kW - 50 hp<

[22] >45 kW - 60 hp<

[23] >55 kW - 75 hp<

[24] >75 kW - 100 hp<

[25] >90 kW - 120 hp<

[26] >110 kW - 150 hp<

1-22 Motor Voltage

1-23 Motor Frequency

1-24 Motor Current

1-25 Motor Nominal Speed

1-26 Motor Cont. Rated Torque

1-29 Automatic Motor Adaption (AMA)

*[0] >Off<

[1] >Enable Complete AMA<

[2] >Enable Reduced AMA<

1-3* Adv. Motor Data I

1-30 Stator Resistance (Rs)

1-33 Stator Leakage Reactance (X1)

1-35 Main Reactance (Xh)

1-37 d-axis Inductance (Ld)

1-39 Motor Poles

1-4* Adv. Motor Data II

1-40 Back EMF at 1000 RPM

1-42 Motor Cable Length

1-43 Motor Cable Length Feet

1-5* Load Indep. Setting

1-50 Motor Magnetisation at Zero Speed

1-52 Min Speed Normal Magnetising [Hz]

1-55 U/f Characteristic - U

1-56 U/f Characteristic - F

1-6* Load Depen. Setting

1-60 Low Speed Load Compensation

1-61 High Speed Load Compensation

1-62 Slip Compensation

1-63 Slip Compensation Time Constant

1-64 Resonance Dampening

1-65 Resonance Dampening Time Constant

1-66 Min. Current at Low Speed

1-7* Start Adjustments

1-71 Start Delay

1-72 Start Function

[0] >DC Hold/delay time<

*[2] >Coast/delay time<

[3] >Start speed cw<

[4] >Horizontal operation<

[5] >VVC+ clockwise<

1-73 Flying Start

*[0] >Disabled<

[1] >Enabled<

[2] >Enabled Always<

[3] >Enabled Ref. Dir.<

[4] >Enab. Always Ref. Dir.<

1-75 Start Speed [Hz]

1-76 Start Current

1-78 Compressor Start Max Speed [Hz]

1-79 Compressor Start Max Time to Trip

1-8* Stop Adjustments

1-80 Function at Stop

*[0] >Coast<

[1] >DC hold / Motor Preheat<

[3] >Pre-magnetizing<

1-82 Min Speed for Function at Stop [Hz]

1-9* Motor Temperature

1-90 Motor Thermal Protection

*[0] >No protection<

[1] >Thermistor warning<

[2] >Thermistor trip<

[3] >ETR warning 1<

[4] >ETR trip 1<

1-93 Thermistor Source

2-** Brakes

2-0* DC-Brake

2-00 DC Hold/Motor Preheat Current

2-01 DC Brake Current

2-02 DC Braking Time

2-04 DC Brake Cut In Speed

2-06 Parking Current

2-07 Parking Time

2-1* Brake Energy Funct.

2-10 Brake Function

*[0] >Off<

[1] >Resistor brake<

[2] >AC brake<

2-11 Brake Resistor (ohm)

2-12 Brake Power Limit (kW)

2-14 Brake voltage reduce

2-16 AC Brake, Max current

2-17 Over-voltage Control

*[0] >Disabled<

[1] >Enabled (not at stop)<

[2] >Enabled<

2-19 Over-voltage Gain

2-2* Mechanical Brake

2-20 Release Brake Current

2-22 Activate Brake Speed [Hz]

3-** Reference / Ramps

3-0* Reference Limits

3-00 Reference Range

*[0] >Min - Max<

[1] >-Max - +Max<

3-01 Reference/Feedback Unit

3-02 Minimum Reference

3-03 Maximum Reference

3-04 Reference Function

*[0] >Sum<

[1] >External/Preset<

3-1* References

3-10 Preset Reference

>-100-100%< *0%

3-11 Jog Speed [Hz]

3-12 Catch up/slow Down Value

3-14 Preset Relative Reference

3-15 Reference 1 Source

[0] >No function<

*[1] >Analog Input 53<

[2] >Analog Input 54<

[7] >Frequency input 29<

[8] >Frequency input 33<

[11] >Local bus reference<

[32] >Bus PCD<

3-16 Reference 2 Source

3-17 Reference 3 Source

3-18 Relative Scaling Reference Resource

3-4* Ramp 1

3-40 Ramp 1 Type

*[0] >Linear<

[2] >S-ramp Const Time<

3-41 Ramp 1 Ramp Up Time

>0.05-3600 s< * Size related

3-42 Ramp 1 Ramp Down Time

>0.05-3600 s< * Size related

3-5* Ramp 2

3-50 Ramp 2 Type

3-51 Ramp 2 Ramp Up Time

3-52 Ramp 2 Ramp Down Time

3-6* Ramp 3

3-60 Ramp 3 Type

3-61 Ramp 3 Ramp up Time

3-7* Ramp 4

3-70 Ramp 4 Type

3-71 Ramp 4 Ramp up Time

3-72 Ramp 4 Ramp Down Time

3-8* Other Ramps

3-80 Jog Ramp Time

3-81 Quick Stop Ramp Time

4-** Limits / Warnings

4-1* Motor Limits

4-10 Motor Speed Direction

[0] >Clockwise<

*[2] >Both directions<

4-12 Motor Speed Low Limit [Hz]

4-14 Motor Speed High Limit [Hz]

4-16 Torque Limit Motor Mode

4-17 Torque Limit Generator Mode

4-18 Current Limit

4-19 Max Output Frequency

4-2* Limit Factors

4-22 Break Away Boost

4-3* Motor Fb Monitor

4-30 Motor Feedback Loss Function

4-31 Motor Feedback Speed Error

4-32 Motor Feedback Loss Timeout

4-4* Adj. Warnings 2

4-40 Warning Freq. Low

4-41 Warning Freq. High

4-42 Adjustable Temperature Warning

4-5* Adj. Warnings

4-50 Warning Current Low

4-51 Warning Current High

4-54 Warning Reference Low

4-55 Warning Reference High

4-56 Warning Feedback Low

4-57 Warning Feedback High

4-58 Missing Motor Phase Function

4-6* Speed Bypass

4-61 Bypass Speed From [Hz]

4-63 Bypass Speed To [Hz]

4-64 Semi-Auto Bypass Set-up
