*[0] >No operation<

[100] >Output frequency<

[101] >Reference<

[102] >Process Feedback<

[103] >Motor Current<

[104] >Torque rel to limit<

[105] >Torq relate to rated<

[106] >Power<

[107] >Speed<

[111] >Speed Feedback<

[113] PID Clamped Output

[139] >Bus Control<

6-72 Terminal 45 Digital Output

6-73 Terminal 45 Output Min Scale

6-74 Terminal 45 Output Max Scale

6-76 Terminal 45 Output Bus Control

6-9* Analog/Digital Output 42

6-90 Terminal 42 Mode

6-91 Terminal 42 Analog Output

6-92 Terminal 42 Digital Output

6-93 Terminal 42 Output Min Scale

6-94 Terminal 42 Output Max Scale

6-96 Terminal 42 Output Bus Control

6-98 Drive Type

7-** Controllers

7-0* Speed PID Ctrl.

7-00 Speed PID Feedback Source

[1] >24V encoder<

[2] >MCB 102<

[3] >MCB 103<

[6] >Analog Input 53<

[7] >Analog Input 54<

[8] >Frequency input 29<

[9] >Frequency input 33<

*[20] >None<

7-02 Speed PID Proportional Gain

>0.000-1.000< *0.015

7-03 Speed PID Integral Time

>2.0-20000.0 ms< *8.0 ms

7-04 Speed PID Differentiation Time

>0.0-200.0 ms< *30.0 ms

7-05 Speed PID Diff. Gain Limit

>1.0-20.0< *5.0

7-06 Speed PID Lowpass Filter Time

>1.0-100.0 ms< *10.0 ms

7-07 Speed PID Feedback Gear Ratio

7-08 Speed PID Feed Forward Factor

7-1* Torque PID Ctrl.

7-12 Torque PID Proportional Gain

7-13 Torque PID Integration Time

7-2* Process Ctrl. Feedb

7-20 Process CL Feedback 1 Resource

*[0] >No function<

[1] >Analog Input 53<

[2] >Analog Input 54<

[3] >Frequency input 29<

[4] >Frequency input 33<

7-22 Process CL Feedback 2 Resource

7-3* Process PID Ctrl.

7-30 Process PID Normal/ Inverse Control

*[0] >Normal<

[1] >Inverse<

7-31 Process PID Anti Windup

[0] >Off<

*[1] >On<

7-32 Process PID Start Speed

>0 - 6000 rpm< *0 rpm

7-33 Process PID Proportional Gain

>0.00 - 10.00< *0.01

7-34 Process PID Integral Time

>0.10-9999.00 s< *9999.00 s

7-35 Process PID Differentiation Time

>0.00-20.00 s< *0.00 s

7-36 Process PID Diff. Gain Limit

7-38 Process PID Feed Forward Factor

>0-200%< *0%

7-39 On Reference Bandwidth

7-4* Adv. Process PID I

7-40 Process PID I-part Reset

7-41 Process PID Output Neg. Clamp

7-42 Process PID Output Pos. Clamp

7-43 Process PID Gain Scale at Min. Ref.

7-44 Process PID Gain Scale at Max. Ref.

7-45 Process PID Feed Fwd Resource

*[0] >No function<

[1] >Analog Input 53<

[2] >Analog Input 54<

[7] >Frequency input 29<

[8] >Frequency input 33<

[11] >Local bus reference<

[32] >Bus PCD<

7-46 Process PID Feed Fwd Normal/ Inv.

Ctrl.

7-48 PCD Feed Forward

7-49 Process PID Output Normal/ Inv. Ctrl.

7-5* Adv. Process PID II

7-50 Process PID Extended PID

7-51 Process PID Feed Fwd Gain

7-52 Process PID Feed Fwd Ramp up

7-53 Process PID Feed Fwd Ramp down

7-56 Process PID Ref. Filter Time

7-57 Process PID Fb. Filter Time

7-6* Feedback Conversion

7-60 Feedback 1 Conversion

*[0] >Linear<

[1] >Square root<

7-62 Feedback 2 Conversion

8-** Comm. and Options

8-0* General Settings

8-01 Control Site

8-02 Control Source

8-03 Control Timeout Time

8-04 Control Timeout Function

8-07 Diagnosis Trigger

8-1* Ctrl. Word Settings

8-10 Control Word Profile

8-14 Configurable Control Word CTW

8-19 Product Code

8-3* FC Port Settings

8-30 Protocol

*[0] >FC<

[2] >Modbus RTU<

8-31 Address

8-32 Baud Rate

[0] >2400 Baud<

[1] >4800 Baud<

*[2] >9600 Baud<

[3] >19200 Baud<

[4] >38400 Baud<

[5] >57600 Baud<

[6] >76800 Baud<

[7] >115200 Baud<

8-33 Parity / Stop Bits

*[0] >Even Parity, 1 Stop Bit<

[1] >Odd Parity, 1 Stop Bit<

[2] >No Parity, 1 Stop Bit<

[3] >No Parity, 2 Stop Bits<

8-35 Minimum Response Delay

8-36 Maximum Response Delay

8-37 Maximum Inter-char delay

8-4* FC MC protocol set

8-43 PCD Read Configuration

8-5* Digital/Bus

8-50 Coasting Select

8-51 Quick Stop Select

8-52 DC Brake Select

8-53 Start Select

8-54 Reversing Select

8-55 Set-up Select

8-56 Preset Reference Select

8-57 Profidrive OFF2 Select

8-58 Profidrive OFF3 Select

8-7* BACnet

8-79 Protocol Firmware Version

8-8* FC Port Diagnostics

8-80 Bus Message Count

8-81 Bus Error Count

8-82 Slave Messages Rcvd

8-83 Slave Error Count

8-84 Slave Messages Sent

8-85 Slave Timeout Errors

8-88 Reset FC port Diagnostics

8-9* Bus Feedback

8-90 Bus Jog 1 Speed

8-91 Bus Jog 2 Speed

9-** PROFIdrive

9-00 Setpoint

9-07 Actual Value

9-15 PCD Write Configuration

9-16 PCD Read Configurariont

9-18 Node Address

9-19 Drive Unit System Number

9-22 Telegram Selection

9-23 Parameters for Signals

9-27 Parameter Edit

9-28 Fault Message Counter

9-45 Fault Code

9-47 Fault Number

9-52 Fault Situation Counter

9-53 Profibus Warning Word

9-63 Actual Baud Rate

9-64 Device Identification

9-65 Profile Number

9-67 Control Word 1

9-68 Status Word 1

9-70 Programming Set-up

9-71 Profibus Save Data Values

9-72 ProfibusDriveReset

9-75 DO Identification

9-80 Defined Parameters (1)

9-81 Defined Parameters (2)

9-82 Defined Parameters (3)

9-83 Defined Parameters (4)

9-84 Defined Parameters (5)

9-90 Changed Parameters (1)

9-91 Changed Parameters (2)

9-92 Changed Parameters (3)

9-93 Changed Parameters (4)

9-94 Changed Parameters (5)

9-99 Profibus Revision Counter

12-** Ethernet

12-0* IP Settings

12-00 IP Address Assignment

12-01 IP Address

12-02 Subnet Mask

12-03 Default Gateway

12-04 DHCP Server

12-05 Lease Expires

12-06 Name Servers

12-07 Domain Name

12-08 Host Name

12-09 Physical Address

12-1* Ethernet Link Parameters

12-10 Link Status

12-11 Link Duration

12-12 Auto Negotiation

12-13 Link Speed

12-14 Link Duplex

12-8* Other Ethernet Services

12-80 FTP Server

12-81 HTTP Server

12-82 SMTP Service

12-89 Transparent Socket Channel Port

12-9* Advanced Ethernet Services

12-90 Cable Diagnostics

12-91 Auto Cross Over

12-92 IGMP Snooping

12-93 Cable Error Length

12-94 Broadcast Storm Filter

12-96 Port Config

12-98 Interface Counters

12-99 Media Counters

13-** Smart Logic

13-0* SLC Settings

13-00 SL Controller Mode

*[0] >Off<

[1] >On<

13-01 Start Event

[0] >False<

[1] >True<

[2] >Running<

[3] >In range<

[4] >On reference<

[7] >Out of current range<

[8] >Below I low<

[9] >Above I high<

[16] >Thermal warning<

[17] >Mains out of range<

[18] >Reversing<

[19] >Warning<

[20] >Alarm (trip)<

[21] >Alarm (trip lock)<

[22] >Comparator 0<

[23] >Comparator 1<

[24] >Comparator 2<

[25] >Comparator 3<

[26] >Logic rule 0<

[27] >Logic rule 1<

[28] >Logic rule 2<

[29] >Logic rule 3<

[33] >Digital input DI18<

[34] >Digital input DI19<

[35] >Digital input DI27<

[36] >Digital input DI29<

*[39] >Start command<

[40] >Drive stopped<

[42] >Auto Reset Trip<

[50] >Comparator 4<

[51] >Comparator 5<

[60] >Logic rule 4<

[61] >Logic rule 5<

[83] >Broken Belt<

13-02 Stop Event

*[0] >Off<

[1] >On<

13-03 Reset SLC

*[0] >Do not reset SLC<

[1] >Reset SLC<

13-1* Comparators

13-10 Comparator Operand

13-11 Comparator Operator

13-12 Comparator Value

13-2* Timers

13-20 SL Controller Timer

13-4* Logic Rules

13-40 Logic Rule Boolean 1

13-41 Logic Rule Operator 1

13-42 Logic Rule Boolean 2

13-43 Logic Rule Operator 2

13-44 Logic Rule Boolean 3

13-5* States

13-51 SL Controller Event

13-52 SL Controller Action
