![Danfoss VLT Refrigeration Drive FC103 FC-103P3K0T2 [110/138] Refrigeration drive design guide](/img/pdf.png)
Danfoss VLT Refrigeration Drive FC103 FC-103P3K0T2 [110/138] Refrigeration drive design guide
![Danfoss VLT Refrigeration Drive FC103 FC-103P3K0T2 [110/138] Refrigeration drive design guide](/views2/1559497/page110/bg6e.png)
Mains supply 3x525-600 V AC Normal overload 110% for 1 minute
Size: P1K1 P1K5 P2K2 P3K0 P3K7 P4K0 P5K5 P7K5
Typical Shaft Output [kW] 1.1 1.5 2.2 3 3.7 4 5.5 7.5
IP20/Chassis A3 A3 A3 A3 A2 A3 A3 A3
IP21/NEMA 1 A3 A3 A3 A3 A2 A3 A3 A3
IP55/Type 12 A5 A5 A5 A5 A5 A5 A5 A5
IP66/NEMA 4X A5 A5 A5 A5 A5 A5 A5 A5
Output current
Continuous
(3x525-550 V) [A]
2.6 2.9 4.1 5.2 - 6.4 9.5 11.5
Intermittent
(3x525-550 V) [A]
2.9 3.2 4.5 5.7 - 7.0 10.5 12.7
Continuous
(3x525-600 V) [A]
2.4 2.7 3.9 4.9 - 6.1 9.0 11.0
Intermittent
(3x525-600 V) [A]
2.6 3.0 4.3 5.4 - 6.7 9.9 12.1
Continuous kVA
(525 V AC) [kVA]
2.5 2.8 3.9 5.0 - 6.1 9.0 11.0
Continuous kVA
(575 V AC) [kVA]
2.4 2.7 3.9 4.9 - 6.1 9.0 11.0
Max. input current
Continuous
(3x525-600 V) [A]
2.4 2.7 4.1 5.2 - 5.8 8.6 10.4
Intermittent
(3x525-600 V) [A]
2.7 3.0 4.5 5.7 - 6.4 9.5 11.5
Additional specifications
Estim. power loss at rated max. load [W]
4)
50 65 92 122 - 145 195 261
IP20 max. cable cross-section (mains, motor,
brake and load sharing) [mm
2
(AWG)]
4, 4, 4 (12, 12, 12)
(min. 0.2 (24))
IP55, IP 66 max. cable cross-section (mains,
motor, brake and load sharing) [mm
2
(AWG)]
4, 4, 4 (12, 12, 12)
(min. 0.2 (24))
Max. cable cross-section with disconnect 6, 4, 4 (12, 12, 12)
Mains disconnect switch included: 4/12
Weight IP20 [kg] 6.5 6.5 6.5 6.5 - 6.5 6.6 6.6
Weight IP21/55 [kg] 13.5 13.5 13.5 13.5 13.5 13.5 14.2 14.2
Efficiency
4)
0.97 0.97 0.97 0.97 - 0.97 0.97 0.97
Table 8.5
5)
With brake and load sharing 95/4/0
General Specifications and ...
VLT
®
Refrigeration Drive Design Guide
MG16G102 - VLT
®
is a registered Danfoss trademark 109
8
8
