en
10
Sabbath mode
When Sabbath mode is switched on, the following
settings are switched off:
■ Super freezing (if it is switched on)
■ Ice maker
■ Acoustic signal
■ Interior light
■ Messages in the display panel
■ The background illumination of the display panel is
reduced.
■ Buttons are locked.
Switching on
1. Press and hold down the “super” button.
2. Press Vacation button.
3. Press “super” button and hold down for 3 seconds
longer.
The symbol VACATION flashes on the display panel
and SABBATH is displayed.
Switching off
Press Vacation button.
The previous settings and temperature values are once
again activated.
Energy saving mode
If the energy saving function (eco function) is activated,
the appliance switches to energy saving operation. This
energy saving function is preset at the factory in order
to reduce energy consumption. The background
illumination of the fascia is likewise reduced.
Switching on
1. Press setup button.
2. Press the selection button ¿, until ECO MODE
and the current setting (OFF) is displayed.
3. Press the setting button @, in order to reset
the setting.
4. Press the setup button, in order to store the setting.
ECO is displayed in the fascia.
Switching off
1. Press setup button.
2. Press the selection button ¿, until ECO MODE
and the current setting (ON) is displayed.
3. Press the setting button A, in order to reset
the setting.
4. Press the setup button, in order to store the setting.
Alarm function
Switching off the warning signal
Press the “alarm” button to switch off the warning
signal.
Door alarm
The door alarm switches on if an appliance door is left
open for longer than three minutes. Close the door
to switch off the warning signal.
Usable capacity
Information on the usable capacity can be found inside
your appliance on the rating plate (see diagram at
chapter “Customer service”).
Freezer compartment
Use the freezer compartment:
■ To store deep-frozen food.
■ To freeze food.
■ To make ice cubes.
Note
Ensure that the freezer compartment door is always
closed properly. If the door is open, the frozen food will
thaw. The freezer compartment will become covered
in thick ice.
Also: Energy will be lost due to high power
consumption.
Purchasing frozen food
■ Packaging must not be damaged.
■ Use by the “use by” date.
■ Temperature in the supermarket freezer must be
-18 °C or lower.
■ If possible, transport deep-frozen food in an
insulated bag and place quickly in the freezer
compartment.
Max. freezing capacity
Information about the max. freezing capacity within
24 hours can be found on the rating plate (see diagram
at chapter “Customer service”).
