Siemens FI24DP32 [15/21] Interior fittings
![Siemens FI24DP32 [15/21] Interior fittings](/views2/1056610/page15/bgf.png)
en
15
Interior fittings
Taking out the shelves
You can reposition the shelves inside the appliance
and the door shelves as required.
Lift the shelves and remove.
Shelves inside the compartment
Door shelves
Containers in the freezer compartment
The containers in the freezer compartment can be
taken out for cleaning.
1. Lift container slightly and take out.
2. Lift container at front slightly and insert into the
runners.
3. Lower container and push back.
Ice cube container
ã=Caution
A full ice cube container is heavy!
Note
Before removing the ice cube container, switch the ice
maker off, see “Ice maker”.
Switching off and
disconnecting the appliance
Switching the appliance off
Press the On/Off button.
Pull out the mains plug.
Disconnecting the appliance
If you do not use the appliance for a prolonged period:
1. Before switching off, it is most important that you
switch the water supply to the appliance off for a few
hours.
2. Take all food out of the appliance.
3. Switch the appliance off.
4. Pull out mains plug or switch off fuse.
5. Empty and clean the ice cube container (see chapter
Cleaning the appliance).
6. Clean the appliance interior (see chapter Cleaning
the appliance).
7. Leave the appliance doors open to prevent odours
from forming.
