![Advanced Control ADV 4.00 M420-M Краткое руководство онлайн [13/72] 459372](/views2/1567038/page13/bgd.png)
Trouble Shooting M420 General Flux Vector Control Inverter User Manual
Display
Fault Name
Possible Causes
Solutions
Err05
Over current
during
deceleration
1: The output circuit is grounded
or short circuited.
2: Motor parameter is not right.
3: The deceleration time is too
short.
4: The voltage is too low.
5: A sudden load is added
during deceleration.
6: The braking unit and braking
resistor are not installed.
7:Magnetic flux brake gain too
much
1: Eliminate external faults.
2: Perform the motor auto-
tuning.
3: Increase the deceleration
time.
4: Adjust the voltage to
normal range.
5: Remove the added load.
6:Install the braking unit and
braking resistor.
7:Decrease the over-
magnetic flux brake gain.
Err06
Over current
at constant
speed
1: The output circuit is grounded
or short circuited.
2: Motor parameter is not right.
3: The voltage is too low.
4: A sudden load is added
during operation.
5: The AC drive model is of too
small.
1: Eliminate external faults.
2: Perform the motor auto-
tuning.
3: Adjust the voltage to
normal range.
4: Remove the added load.
5: Select an AC drive of
higher power class.
Err08
Overvoltage
during
acceleration
1
：
The input voltage is too high.
2
：
An external force drives the
motor during acceleration.
3
：
The acceleration time is too
short.
4
：
The braking unit and braking
resistor are not installed.
5
：
Motor parameter is wrong.
1
：
Adjust the voltage to
normal range.
2
：
Cancel the external force
or install a braking resistor.
3
：
Increase the acceleration
time.
4
：
Install the braking unit
and braking resistor.
5
：
Perform the motor
auto-tuning.
Err09
Overvoltage
during
deceleration
1
：
The input voltage is too high.
2
：
An external force drives the
motor during deceleration.
3
：
The deceleration time is too
short.
4
：
The braking unit and braking
resistor are not installed.
1
：
Adjust the voltage to
normal range.
2
：
Cancel the external force
or install a braking resistor.
3
：
Increase the deceleration
time.
4
：
Install the braking unit
and braking resistor.
Err10
Overvoltage
at constant
speed
1
：
The input voltage is too high.
2
：
An external force drives the
motor during acceleration.
1
：
Adjust the voltage to
normal range.
2
：
Cancel the external force
