M420 General Flux Vector Control Inverter User Manual Trouble Shooting
13
Display
Fault Name
Possible Causes
Solutions
or install a braking resistor.
Err12
Undervoltage
1. Instantaneous power failure
occurs.
2. The input voltage exceeds the
allowed range.
3.
The DC bus voltage is too low.
4. The rectifier bridge and
Buffer resistor are faulty.
5. The drive board is faulty.
6. The control board is faulty.
1. Reset the fault.
2. Adjust the input voltage to
within the allowed range.
3. Seek for maintenance.
Err13
Drive
overload
1. The load is too heavy or the
rotor is locked.
2. The drive is of too small
power class.
1: Reduce the load, or check
the motor, or check the
machine whether it is
locking the rotor.
2: Select a drive of higher
power class.
Err14
Motor
overload
1: F9-01istoosmall.
2: The load is too heavy or the
rotor is locked.
3: The drive is of too small
power class.
1: SetF9-01correctly.
2: Reduce the load,or check
the motor, or check the
machine whether it is
locking the rotor.
3: Select a drive of higher
power class.
Err15
Drive
overheat
1: The ambient temperature is
too high.
2: The air filter is blocked.
3: The cooling fan is damaged.
4: The thermally sensitive
resistor of the module is
damaged.
5: The inverter module is
damaged.
1: Lower the ambient
temperature.
2: Clean the air filter.
3: Replace the damaged fan.
4: Replace the damaged
thermally sensitive resistor.
5: Replace the inverter
module.
Err17
Current
detection
fault
1: The internal connections
become loose.
2: The HALL device is faulty.
3: The control or drive board is
faulty.
1: Connect all cables
properly.
2: Seek for maintenance.
Err20
Short circuit
to ground
The motor is short circuited to
the ground.
Replace the cable or motor.
