Trouble Shooting M420 General Flux Vector Control Inverter User Manual
Display
Fault Name
Possible Causes
Solutions
Err23
Power input
phase loss
1: The three-phase power input
is abnormal.
2: The drive board is faulty.
3: The lightening board is faulty.
4: The main control board is
faulty.
1: Eliminate external faults.
2: Seek for maintenance.
Err24
Power output
phase loss
1: The cable connecting the AC
drive and the motor is faulty.
2: The AC drive's three-phase
outputs are unbalanced when the
motor is running.
3: The drive board is faulty.
4 The module is faulty.
1: Eliminate external faults.
2: Check whether the motor
three-phase winding is
normal.
3: Seek for maintenance.
Err25
EEPROM
read-write fault
The EEPROM chip is damaged.
Replace the main control
board.
Err27
Comm
unication
fault
1: The host computer is in
abnormal state.
2: The communication cable is
faulty.
3: The communication
parameters in group F8 are set
improperly.
1: Check cabling of the host
computer.
2: Check the communication
cabling.
3: Set the communication
parameters properly.
Err28
External
equipment
fault
External fault normally closed or
normally open signal is input via
DI.
Reset the fault.
Err29
Too large
speed
deviation
1: The load is too heavy and the
acceleration time is too short.
2: F9-31 and F9-32 are set
incorrectly.
1: Increase the acceleration
and deceleration time.
2: Set F9-31 and F9-32
correctly based on the actual
situation.
Err30
User-definedf
ault1
Theuser-definedfault1signalisinp
utviaDI.
Reset the fault.
Err31
User-definedf
ault2
Theuser-definedfault2signalisinp
utviaDI.
Reset the fault.
Err32
PID feedback
lost during
running
The PID feedback is lower than
the setting of FA-13.
Check the PID feedback
signal or set FA-26 to a
proper value.
